Sans Digital AccuRAID DAS Array ST-SAN-AR442F8R AR442F8R

The AccuRAID AR442F8R series is a high density 4U rackmount designed for storage hungry applications, and accommodates up to 126TB of storage space. The unit utilizes advanced Fibre technology when operating as direct attached storage (DAS), and could be setup as a storage area network (SAN) with the assistance of a Fibre Channel network switch. In addition, the quad Fibre Channel ports allow the support of clustering, where the unit could be accessed by multiple servers, ensuring continuous uptime in a production environment.To reinforce the AR442F8R's ability to overcome hardware failure, two redundant and hot-swappable power supplies and cooling fans are available for added safeguard. Active-Active redundant controllers allows further failure protection when needed. Internally, the AR442F8R supports up to RAID 60, with RAID monitoring, RAID notification, automatic failover, and automatic recovery. Build-in expansion port allow up to two additional JBOD unit (AS424X6R) with up to 126 bays or 378TB. The unit's built-in Ethernet port with web based management console and SES management features provide instant access to the status of the RAID array and the enclosure to reduce downtime. SAS drives is supported, while SATA can be used with additional mux board.

Product Type	DAS Array
Brand Name	Sans Digital
Manufacturer	Sans Digital
Product Model	AR442F8R
Product Name	AccuRAID AR442F8R DAS Array
Product Line	AccuRAID
Manufacturer Part Number	ST-SAN-AR442F8R
Manufacturer Website Address	http://www.sansdigital.com
RAID Supported	Yes
Controller Type	Serial ATASerial Attached SCSI (SAS)
Number of Total Expansion Bays	42
Number of 5.25" Bays	No
Number of 2.5"/3.5" Bays	42
Total Hard Drive Capacity Supported	126 TB
Total Solid State Drive Capacity Supported	126 TB
Number of Hard Drives Supported	42
Number of Hard Drives Installed	No
Number of Solid State Drive Supported	42
Number of Solid State Drive Installed	No
Height	7"
Width	19"
Depth	30.7"
Rack Height	4U
Form Factor	Rack-mountable
Weight (Approximate)	100 lb
Limited Warranty	3 Year
Host Interface	Fibre Channel
