Sans Digital AccuRAID DAS Array ST-SAN-AR464F8R AR464F8R

The AccuRAID AR464F8R series is a very high density 4U rackmount designed for storage hungry applications, and accommodates up to 192TB of storage space, using revolutionary top-loaded design. The unit utilizes advanced 8G fibre channel interface technology operating as direct attached storage (DAS). In addition, the dual controller, total of 8 channel fibre channel ports allow the support of clustering, where the unit could be accessed by two servers, ensuring continuous uptime in a production environment.To reinforce the AR464F8R's ability to overcome hardware failure, two redundant and hot-swappable power supplies and cooling fans are available for added safeguard. Active-Active redundant controllers allows further failure protection when needed. Internally, the AR464F8R supports up to RAID 60, with RAID monitoring, RAID notification, automatic failover, and automatic recovery. Build-in expansion port allow additional JBOD unit (AS464X6R) with up to 128 bays. The unit's built-in Ethernet port with web based management console and SES management features provide instant access to the status of the RAID array and the enclosure to reduce downtime. SAS drives is supported, while SATA can be used with additional MUX board.AR464F8R's 4U 64-bay top-loaded high density design provide space saving, allow fewer power outlet, which in term generate less-heat, requires less cooling and saving on energy cost, providing an ideal solution for high capacity storage needs.

Product Type	DAS Array
Brand Name	Sans Digital
Manufacturer	Sans Digital
Product Model	AR464F8R
Product Name	AccuRAID AR464F8R DAS Array
Product Line	AccuRAID
Manufacturer Part Number	ST-SAN-AR464F8R
Manufacturer Website Address	http://www.sansdigital.com
RAID Supported	Yes
Controller Type	Serial ATASerial Attached SCSI (SAS)
Number of Total Expansion Bays	64
Number of 5.25" Bays	No
Number of 2.5"/3.5" Bays	64
Total Hard Drive Capacity Supported	192 TB
Total Solid State Drive Capacity Supported	192 TB
Number of Hard Drives Supported	64
Number of Hard Drives Installed	No
Number of Solid State Drive Supported	64
Number of Solid State Drive Installed	No
Height	7"
Width	19"
Depth	35.4"
Rack Height	4U
Form Factor	Rack-mountable
Weight (Approximate)	100 lb
Limited Warranty	3 Year
Host Interface	Fibre Channel
