Sans Digital TowerRAID - 4 Bay 6G SAS / SATA Modularize JBOD Storage Enclosure (Black) ST-SAN-TR4X6G TR4X6G

The TowerRAID TR4X6G is a 4-bay tower with a single mini-SAS connection, for high transfer rates of up to 2,400MB/s when used with a high performance RAID controller card. Utilizing high bandwidth mini-SAS (SFF-8088) cabling, the TR4X6G supports 6G SAS or 6G SATA hard drives to deliver superior read / write speeds that are crucial in performance-driven environments such as video editing industry and server application. The mini-SAS ports combine four hard drives connections into one, reducing possible points of failures, while preserving uninterrupted data transfer. The TR4X6G also supports SATA drives, allowing users the option to choose between high performance and high capacity storage solutions. Hard drive and RAID controller bundles options are available. When utilizing a SAS or SATA RAID controller, the unit could effortlessly support multi-streaming of compressed high-quality playback or a single-stream of uncompressed 10-bit high definition video under various RAID modes.

Product Type	Drive Enclosure
Brand Name	Sans Digital
Manufacturer	Sans Digital
Product Model	TR4X6G
Product Name	TowerRAID TR4X6G - 4 Bay 6G SAS / SATA Modularize JBOD Storage Enclosure (Black)
Product Line	TowerRAID
Manufacturer Part Number	ST-SAN-TR4X6G
Manufacturer Website Address	http://www.sansdigital.com
Packaged Quantity	1
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	TowerRAID TR4X6G - 4 Bay 6G SAS / SATA Modularize JBOD Storage Enclosure (Black) 4 x Hot-swappable Trays 1 x Power Cord 1 x Mini-SAS to Mini-SAS Cable 1 x Set of Screws 1 x Quick Installation Manual & CD
Number of Total Expansion Bays	4
Number of 3.5" Bays	4
Number of 5.25" Bays	No
Number of 2.5" Bays	No
Number of 2.5"/3.5" Bays	No
Number of 1.8" Bays	No
Number of Hard Drives Supported	4
Number of Hard Drives Installed	No
Cooling Fan	Yes
Height	8.3"
Width	6"
Depth	11"
Color	Black
Form Factor	Compact Tower
Weight (Approximate)	9.30 lb
Non-RAID Mode	JBOD
Limited Warranty	1 Year
Host Interface	Mini-SAS
