Server Technology Switched PDU - 1.9kW C1W08HC-1ACA2BA5

The Server Technology® PRO1 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Switched "Master" PDU can be connected to as many as three (with optional module) PRO1 Switched "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.

Network (RJ-45)	Yes
Product Type	PDU
Manufacturer Part Number	C1W08HC-1ACA2BA5
Manufacturer Website Address	http://www.servertech.com
Manufacturer	Server Technology, Inc
Product Model	C1W08HC-1ACA2BA5
Product Name	Switched PDU - 1.9kW, C1W08HC-1ACA2BA5
Product Series	PRO1
Brand Name	Server Technology
Management	SSH SMTP Syslog HTTP/HTTPS TLSv1.2 SSHv2 Telnet SNMPv2c and v3 (GET, SET, Traps) IPv4 and IPv6 LDAPv3/LDAPS TACACS+ RADIUS FTP/SFTP
Country of Origin	United States
Environmentally Friendly	Yes
Environmental Certification	RoHS WEEE
Mount Type	Rack-mountable
Height	1.8"
Width	17.2"
Depth	7"
Input Voltage	120 V AC
Output Voltage	120 V AC
Input Current	20 A
Power Rating (Watt)	1900 W
Protection Type	Fuse Single Pole
Plug/Connector Type	C20 Inlet
Phase	Three Phase
Receptacle Type	NEMA 5-20R
PDU Type	Switched
Receptacle Detail	8 x NEMA 5-20R
Limited Warranty	2 Year
