Server Technology Smart PDU - 8.6kW C2S48TE-DCMFAM99

The Server Technology® PRO2 Smart PDU provides local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Smart Master" PDU can be connected to as many as three (with optional module) PRO2 Smart "Link"

Network (RJ-45)	Yes
Product Type	PDU
Manufacturer Part Number	C2S48TE-DCMFAM99
Manufacturer Website Address	http://www.servertech.com
Manufacturer	Server Technology, Inc
Product Model	C2S48TE-DCMFAM99
Product Name	Smart PDU - 8.6kW, C2S48TE-DCMFAM99
Product Line	PRO2
Product Series	Smart
Brand Name	Server Technology
Package Contents	Smart PDU - 8.6kW, C2S48TE-DCMFAM99 Button Mounts
Form Factor	Rack/Tower
Mount Type	Cabinet-mountable Rack-mountable
Height	80"
Width	2.2"
Depth	2.5"
Input Voltage	208 V
Input Current	30 A
Power Rating (Watt)	8600 W
Protection Type	Overcurrent Protection Overload Protection Circuit Protection
Plug/Connector Type	NEMA L15-30P
Phase	Three Phase
Receptacle Type	IEC 60320 C13 CX
PDU Type	Monitored
Receptacle Detail	30 x IEC 60320 C13 18 x CX
Plug/Connector Detail	1 x NEMA L15-30P
Limited Warranty	2 Year
