Server Technology PRO1 24-Outlets PDU STV-4541C

The Server Technology® PRO1 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Switched "Master" PDU can be connected to as many as three (with optional module) PRO1 Switched "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.

Network (RJ-45)	Yes
Product Type	PDU
Manufacturer Part Number	STV-4541C
Manufacturer Website Address	http://www.servertech.com
Manufacturer	Server Technology, Inc
Product Model	STV-4541C
Product Name	PRO1 STV-4541C 24-Outlets PDU
Product Series	PRO1
Brand Name	Server Technology
Management	HTTP/HTTPS TLSv1.2 SSHv2 Telnet SNMPv2c IPv4 IPv6 LDAPv3/LDAPS TACACS+ RADIUS FTP/SFTP v3 (GET, SET, Traps)
Package Contents	PRO1 STV-4541C 24-Outlets PDU Button Mounts Mounts
Mount Type	Rack-mountable Cabinet-mountable
Rack Height	0U
Height	69"
Width	1.8"
Depth	2.3"
Input Voltage	230 V AC
Input Current	30 A
Power Rating (Watt)	5000 W
Protection Type	Double Pole Overload Protection Circuit Protection
Plug/Connector Type	NEMA L6-30P
Phase	Three Phase
Receptacle Type	IEC 60320 C13 IEC 60320 C19
PDU Type	Switched
Receptacle Detail	18 x IEC 60320 C13 6 x IEC 60320 C19
Limited Warranty	2 Year
