Shuttle XPC Slim Barebone System XH310R

Affordable 3-litre PC for demanding tasksThe Shuttle XPC slim Barebone XH310R is a real roomster considering its small footprint - one optical drive, two 2.5" storage drives and an M.2 SSD card can be installed into the robust steel chassis. It supports the powerful Intel Core desktop processors with socket LGA1151v2. The built-in heatpipe cooling ensures the system runs quietly and reliable. Thanks to its great connectivity it meets the requirements of many applications that extends from office PC up to industrial applications. The system supports two displays with Ultra HD resolution, dual LAN, eight USB ports and up to five serial ports. With this high level of efficiency and flexibility - who needs a bulky tower PC anyway?

Number of SATA Interfaces	3
Total Number of USB Ports	9
Number of Onboard USB 2.0 Ports	1
Number of USB 3.1 Gen 1 Ports	4
HDMI (Rear)	Yes
Controller Type	Serial ATA/600
Graphics Controller Manufacturer	Intel
Graphics Controller Model	UHD Graphics
Graphics Memory Technology	DDR4 SDRAM
Graphics Memory Accessibility	Shared
Product Type	Barebone System
Manufacturer Part Number	XH310R
Manufacturer Website Address	http://www.us.shuttle.com
Manufacturer	Shuttle, Inc
Product Model	XH310R
Product Name	XPC Slim XH310R Barebone System
Product Line	XPC slim
Brand Name	Shuttle
Number of Internal 2.5" Bays	2
Number of Total Expansion Bays	2
Maximum Memory Supported	64 GB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2666/PC4-21333
Number of Total Memory Slots	2
Package Contents	XPC Slim XH310R Barebone System External Power Adapter with 1.7m AC Power Cord (with protective-earth contacts) Multi-language Installation Guide (EN, DE, FR, ES, JP, KR, SC, TC) DVD with Windows 10 Driver Software and Manuals in PDF Format Pre-installed SATA and Power Cables for One 2.5" Drive and One Slimline Drive Protector Cap for the CPU Socket (do not use if heat-pipe or fan is mounted) CPU Heatpipe Cooling System with Heatsink Compound 2 x Screws for Installation of Two M.2 Cards 8 x Screws for Installation of Two 2.5" Drives 2 x Screws for Installation of an Optional Slimline Drive
Country of Origin	China
Environmentally Friendly	Yes
Environmental Certification	ErP ENERGY STAR 5.0 RoHS
Energy Star	Yes
Ethernet Technology	Gigabit Ethernet
Weight (Approximate)	4.85 lb
Form Factor	Slim PC
Height	2.9"
Width	7.9"
Depth	9.4"
Product Color	Black
Input Voltage	120 V AC 230 V AC
Maximum Power Supply Wattage	90 W
Limited Warranty	3 Year
Processor Supported	Core i9 Core i7 Core i5 Core i3 Pentium Gold Celeron Pentium
Processor Socket	Socket H4 LGA-1151
64-bit Processing	Yes
Number of Processors Supported	1
Chipset Manufacturer	Intel
Chipset Model	H310
Operating System Supported	Windows 10 Linux
