SmartAVI MXCORE Expandable HDMI 16X12 Matrix Switcher MXC-HD16X12S

The MXCore-HD HDMI matrix router allows users to distribute and route inputs from various HD sources onto multiple HD displays. Offering high-resolution support of up to 1080p as well as 7.1 digital surround sound audio without any loss of picture clarity and eliminating ghost imaging. The HDMI advantage allows the transmission of both audio and video signals simultaneously through a single cable. The HDMI cable is automatically equalized and can compensate the long distance by reducing the number of additional input signals required. MXCore-HD series also supports HDMI 1.4 while conforming to HDCP standards and DVI 1.0 protocols with 12-bit color depth of all HDTV resolutions including 1080p/60 and 1920 x 1200 for PC resolutions.

Product Type	Audio/Video Switchbox
Product Series	MXCORE-HD
Brand Name	SmartAVI
Manufacturer	Smart Audio Video Innovation
Product Model	MXC-HD16X12S
Product Name	MXCORE Expandable HDMI 16X12 Matrix Switcher
Manufacturer Part Number	MXC-HD16X12S
Manufacturer Website Address	http://www.smartavi.com
Graphics Modes	WUXGA
Maximum Video Resolution	1920 x 1200
Number of HDMI Inputs	16
Number of HDMI Outputs	12
HDMI In	Yes
HDMI Out	Yes
Number of Displays Supported	12
Number of Input Devices Supported	16
Connectivity Technology	Cable
Device Supported	DisplayComputerTV
Country of Origin	United States
Package Contents	MXCORE Expandable HDMI 16X12 Matrix Switcher CCPWR06 Power Plug Cable SM-CSW Software
Height	12"
Width	17.1"
Depth	12"
Form Factor	Rack-mountable
Weight (Approximate)	25 lb
Limited Warranty	1 Year
