SmartAVI CAT5 Audio/Video and IR/RS232 16IN X 16OUT Matrix with RS-232 Control CSWP16X16S

For WUXGA, Component Video, Composite Video and S-Video with full stereo audio support and full IR/RS232 non-blocking matrix switching. Also supports pass-through IR and RS-232 for remote control of compliant devices. Switch up to 16 remote devices to 16 remote displays located up to 1,000 feet away. Supports high resolution video up to 1920×1200. High quality audio switching. Infrared, RS232 and TCP/IP control. Pass-through IR and RS-232 for remote device control. PC Windows software control. Integral UTP distribution. 1U rackmounted chassis. Uses easy to install, inexpensive CAT-5/5e/6/7/8. Maximum extension of 1,500 feet (500m) between the local and remote units. HDTV compatible. (720p, 1080i,1080p) 300 MHz bandwidth. Compatible with VGA, XGA, Sun, MAC and SGI. Sync Format / Polarity Preservation. Compatible with Line Level Stereo Audio Signals. High ground loop immunity. Built-in power surge and transient protection. Designated trimmer in the remote unit to compensate for length

Product Type	Audio/Video Switchbox
Brand Name	SmartAVI
Manufacturer	Smart Audio Video Innovation
Product Model	CSWP16X16S
Product Name	CAT5 Audio/Video and IR/RS232 16IN X 16OUT Matrix with RS-232 Control
Product Line	CATSwitchPro
Manufacturer Part Number	CSWP16X16S
Manufacturer Website Address	http://www.smartavi.com
Graphics Modes	WUXGA
Maximum Video Resolution	1920 x 1200
Maximum Operating Distance	1500 ft
Media Type Supported	Twisted Pair
Number of Displays Supported	16
Number of Input Devices Supported	16
Connectivity Technology	Cable
Device Supported	DisplayComputerDVRCameraGaming Console
Connectivity (RJ-45)	Yes
Number of Connectivity (RJ-45) Ports	32
Country of Origin	United States
Height	5.2"
Width	19"
Depth	18"
Form Factor	Rack-mountable
Weight (Approximate)	22 lb
Limited Warranty	1 Year
