SmartAVI HDMI 16x16 Matrix Switcher HDR16X16S

The HDR 16x16 conforms to the HDMI 1.4 standard and provides a connection to view any sixteen HDMI video sources on any combination of sixteen video displays. The matrix configuration provides maximum flexibility, allowing switching between any high-definition source and/or display. The HDR 16x16 provides HDMI output up to 40 feet with HDTV resolutions of 480p, 720p, 1080i and 1080p. The system works with Blu-ray players, TiVo systems, HT PCs and satellite set-top boxes that connect to an HDMI display. Users can switch to any source locally or remotely via a RS-232, IR, USB or TCP/IP connection. Our HDMI router is controlled by Windows®-based software that is easy to understand and simple to use - a cornerstone of all SmartAVI products.

Product Type	Audio/Video Switchbox
Brand Name	SmartAVI
Manufacturer	Smart Audio Video Innovation
Product Model	HDR16X16S
Product Name	HDMI 16x16 Matrix Switcher
Manufacturer Part Number	HDR16X16S
Manufacturer Website Address	http://www.smartavi.com
Graphics Modes	Full HD
Maximum Video Resolution	1920 x 1080
Environmentally Friendly	Yes
Environmental Certification	RoHS
Country of Origin	United States
Package Contents	HDMI 16x16 Matrix Switcher SM-CSW Software CCPWR06 Cable
Maximum Operating Distance	40 ft
Number of HDMI Inputs	16
Number of HDMI Outputs	16
HDMI In	Yes
HDMI Out	Yes
Number of Displays Supported	16
Number of Input Devices Supported	16
Connectivity Technology	Cable
Device Supported	CameraComputerGaming ConsoleDisplayBlu-ray Disc PlayerDigital Signage
Height	5.3"
Width	19"
Depth	13"
Form Factor	Rack-mountable
Weight (Approximate)	15 lb
Limited Warranty	1 Year
