StarTech.com Transceiver/Media Converter IMC1GSFP

An industrial media converter that converts fiber to copper at a network endpoint. A Flexible Solution Covering Different Requirements This media converter features an open SFP slot for any standard gigabit SFP to be used for the incoming fiber connection and is easily deployed across applications or fiber cable types. Accepts terminal block power or coaxial power connectors with the barrel plug adapter, allowing the product to be hardwired or powered using an external power supply (not included), which does not require professional installation. It can be powered using 12V-56V DC for solar, automotive, rail, and other applications and requires a minimum 12V power input. Includes hardware for DIN rail or wall mounting. For Mission-Critical Applications Designed with IP-30 housing and has an MBTF of >500,000 hrs (Telcordia/Bellcore) at 50°C and an operating temperature range of include -40 C to 75 C for durability; it's rated to various vibration, shock, and free-fall standards: Vibration: EN 60068-2-6 Shock: EN 60068-2-27 Free-Fall: EN 60068-2-32 The IMC1GSFP is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Number of Network (RJ-45) Ports	1
Network (RJ-45)	Yes
Total Number of Ports	1
Product Type	Transceiver/Media Converter
Manufacturer Part Number	IMC1GSFP
Manufacturer Website Address	http://www.startech.com
Manufacturer	StarTech.com
Product Name	Transceiver/Media Converter
Brand Name	StarTech.com
Expansion Slot Type	SFP (mini-GBIC)
Number of Total Expansion Slots	1
Number of SFP Slots	1
Media Type Supported	Optical Fiber Twisted Pair
Fiber Mode Supported	Multi-mode Single-mode
Package Contents	Transceiver/Media Converter Mounting Hardware Kit Quick-Start Guide Terminal Block to Barrel Power Connector Adapter Terminal Block
Country of Origin	Taiwan
Environmentally Friendly	Yes
Environmental Certification	RoHS WEEE
Network Technology	1000Base-T 1000Base-X
Ethernet Technology	Gigabit Ethernet
Weight (Approximate)	5.10 oz
Form Factor	DIN Rail Mountable Wall Mountable
Height	1.3"
Width	3.2"
Depth	4.1"
Power Source	Power Supply
Power Consumption	3 W
Plug/Connector Type	Terminal Block (4 Wire) Type N
Limited Warranty	2 Year
