Wholesale Pricing for Business, Government & You! Transceiver/Media Converter IMC1GSFP Transceiver/Media Converter IMC1GSFP
Mfg Number: IMC1GSFP
Condition: New
UPC: 065030889612
An industrial media converter that converts fiber to copper at a network endpoint. A Flexible Solution Covering Different Requirements This media converter features an open SFP slot for any standard gigabit SFP to be used for the incoming fiber connection and is easily deployed across applications or fiber cable types. Accepts terminal block power or coaxial power connectors with the barrel plug adapter, allowing the product to be hardwired or powered using an external power supply (not included), which does not require professional installation. It can be powered using 12V-56V DC for solar, automotive, rail, and other applications and requires a minimum 12V power input. Includes hardware for DIN rail or wall mounting. For Mission-Critical Applications Designed with IP-30 housing and has an MBTF of >500,000 hrs (Telcordia/Bellcore) at 50°C and an operating temperature range of include -40 C to 75 C for durability; it's rated to various vibration, shock, and free-fall standards: Vibration: EN 60068-2-6 Shock: EN 60068-2-27 Free-Fall: EN 60068-2-32 The IMC1GSFP is backed by a 2-year warranty and free lifetime technical support.
Product Type Transceiver/Media Converter
Brand Name
Product Name Transceiver/Media Converter
Manufacturer Part Number IMC1GSFP
Manufacturer Website Address
Environmentally Friendly Yes
Environmental Certification RoHS WEEE
Country of Origin Taiwan
Package Contents
  • Transceiver/Media Converter
  • Mounting Hardware Kit
  • Quick-Start Guide
  • Terminal Block to Barrel Power Connector Adapter
  • Terminal Block
Ethernet Technology Gigabit Ethernet
Network Technology 1000Base-T 1000Base-X
Number of Total Expansion Slots 1
Number of SFP Slots 1
Expansion Slot Type SFP (mini-GBIC)
Number of Network (RJ-45) Ports 1
Network (RJ-45) Yes
Total Number of Ports 1
Media Type Supported Optical Fiber Twisted Pair
Fiber Mode Supported Multi-mode Single-mode
Height 1.3"
Width 3.2"
Depth 4.1"
Form Factor DIN Rail Mountable Wall Mountable
Weight (Approximate) 5.10 oz
Plug/Connector Type Terminal Block (4 Wire) Type N
Power Source Power Supply
Limited Warranty 2 Year
