Supermicro MicroBlade SDN Switch Module MBM-XEM-001

The 10 Gigabit Ethernet switch modules (part ID MBM-XEM-001) include connection to the MicroBlade's LAN interfaces. While MBM-XEM-001 connect to the LAN interfaces onboard the Blade servers. These are layer 2 Ethernet switching modules also have two internal Ethernet paths to the MicroBlade Chassis Management Module CMM(s) to allow configuration and management of the switch. Offering such advanced features as link aggregation, VLAN, Spanning Tree, Access Control Lists and Jumbo Frame support, the switches provide a connection between the Ethernet controllers integrated on the mainboard to the external Ethernet systems.

Product Type	Expansion Module
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Name	MicroBlade SDN Switch Module (MBM-XEM-001)
Product Line	MicroBlade
Manufacturer Part Number	MBM-XEM-001
Manufacturer Website Address	http://www.supermicro.com
Ethernet Technology	Gigabit Ethernet40 Gigabit Ethernet
Media Type Supported	Optical Fiber
Network Technology	40GBase-X1000Base-X
Number of Total Expansion Slots	4
Expansion Slot Type	QSFP
Height	1.4"
Width	10.5"
Depth	6.3"
Weight (Approximate)	3.20 lb
Application/Usage	Optical NetworkData Networking
Interfaces/Ports Details	1 x USB1 x Console
