Supermicro SuperServer (Black) SSG-5028R-E1CR12L 5028R-E1CR12L

Designed to deliver solid performance and mission-critical reliability for customer applications, these Supermicro uni-processor 2U rack servers support the latest Xeon® processor E5-2600/1600 v3 family and deliver additional levels of performance, power-efficiency and reliability.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	5028R-E1CR12L
Product Name	SuperServer 5028R-E1CR12L (Black)
Product Line	SuperServer
Manufacturer Part Number	SSG-5028R-E1CR12L
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer 5028R-E1CR12L (Black) 1 x Super X10SRH-CLN4F Motherboard 1 x 2U Chassis 1 x SAS 12G single expander backplane, with LSISAS3x28 expander, support 12x 3.5 2 x Internal Mini-SAS HD to Mini-SAS HD 25cm,30AWG,HF,RoHS/REACH,PBF 2 x Internal Mini-SAS HD to Mini-SAS HD 35cm,30AWG,12Gb/s,HF,RoHS/REACH,PBF 1 x CAUTION LABEL FOR REDUNDANT PWR SYSTEMS 1 x SSG-5028R-E1CR12L, QRG,HF,RoHS/REACH 1 x STD I/O shield for X9 socket R server MB with Gasket. 1 x 2U Passive CPU Heat Sink for X9, X10 Generation Systems Equipped w/ a Narrow ILM MB 1 x 8-port Mini SAS HD Int-to-Ext cable adapter w/ LP bracket,HF,RoHS/REACH 2 x 920W 1U Redundant PWS W/ Quiet Mode 12 x Black 3.5" HDD tray
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612
Number of Processors Supported	1
Processor Socket	Socket LGA 2011-v3
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	10
Number of SAS Interfaces	8
Total Number of USB Ports	4
Number of USB 3.0 Ports	2
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	920 W
Number of Total Memory Slots	8
Memory Standard	DDR4-2133/PC4-17000
Memory Technology	DDR4 SDRAM
Maximum Memory	512 GB
RAID Supported	Yes
Controller Type	12Gb/s SASSerial ATA/600
Ethernet Technology	Gigabit EthernetFast Ethernet
Number of Total Expansion Bays	12
Number of 3.5" Bays	12
Number of Total Expansion Slots	6
Number of PCI Express x4 Slots	1
Number of PCI Express x8 Slots	4
Number of PCI Express x16 Slots	1
Height	3.5"
Width	17.2"
Depth	25.6"
Color	Black
Rack Height	2U
Form Factor	Rack-mountable
Weight (Approximate)	33.95 lb
Limited Warranty	3 Year
