Supermicro SuperServer (Black) SSG-6028R-E1CR12H 6028R-E1CR12H

Supermicro's X10 Broadwell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	6028R-E1CR12H
Product Name	SuperServer 6028R-E1CR12H (Black)
Product Line	SuperServer
Manufacturer Part Number	SSG-6028R-E1CR12H
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer 6028R-E1CR12H (Black) 1 x Super X10DRH-iT Motherboard 1 x 2U Chassis 1 x 12-Port 2U Backplane with Expander support up to 8 x 3.5" SAS3/SATA3 HDD/SDD and 4 x SAS3/SATA3/NVMe Storage Devices,HF,RoHS/REACH 4 x Internal Mini-SAS HD to Mini-SAS HD 50cm,30AWG,12Gb/s,HF,RoHS/REACH,PBF 1 x CAUTION LABEL FOR REDUNDANT PWR SYSTEMS 1 x STD I/O shield for X9 socket R server MB with Gasket. 2 x 2U Passive CPU Heat Sink for X9, X10 Generation Systems Equipped w/ a Narrow ILM MB 2 x 920W 1U Redundant PWS W/ Quiet Mode 3 x 80x80x38 mm 7K RPM Chassis Middle Fan w/ Housing 12 x Black 3.5" HDD tray 1 x SAS-3, GEN-3 RAID card. Supports 12Gb and RAID 0, 1, 5, 6, 10, 50, and 60. Includes 2GB memory 1 x 8-port Mini SAS HD Int-to-Ext cable adapter w/ LP bracket
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612
Number of Processors Supported	2
Processor Socket	Socket R3 LGA-2011
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	920 W
Input Voltage	120 V AC230 V AC
Number of Total Memory Slots	16
Memory Standard	DDR4-2400/PC4-19200
Memory Technology	DDR4 SDRAM
Maximum Memory	2 TB
RAID Supported	Yes
Controller Type	12Gb/s SASSerial ATA/600
Ethernet Technology	10 Gigabit EthernetFast Ethernet
Number of Total Expansion Bays	12
Number of 3.5" Bays	12
Number of Total Expansion Slots	7
Number of PCI Express x8 Slots	6
Number of PCI Express x16 Slots	1
Total Number of USB Ports	5
Number of USB 3.0 Ports	2
Height	3.5"
Width	17.2"
Depth	25.6"
Color	Black
Rack Height	2U
Form Factor	Rack-mountable
Weight (Approximate)	34 lb
Limited Warranty	3 Year
