Supermicro SuperServer (Black) SSG-6048R-E1CR24H 6048R-E1CR24H

Designed for optimal performance, the dual-processor SuperServer 7048 series and the uni-processor SuperServer 5048 series support the QPI (9.6 GT/s) format Xeon® E5-2600 v3 Family processors in a high-density 4U form-factor. The 7048 SuperServer have excellent expansion capability and feature set while 5048 SuperServer is optimized as storage powerhouse.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	6048R-E1CR24H
Product Name	SuperServer 6048R-E1CR24H (Black)
Product Line	SuperServer
Manufacturer Part Number	SSG-6048R-E1CR24H
Manufacturer Website Address	http://www.supermicro.com
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612
Number of Processors Supported	2
Processor Socket	Socket LGA 2011-v3
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	920 W
Input Voltage	120 V AC230 V AC
Number of Total Memory Slots	16
Memory Standard	DDR4-2133/PC4-17000
Memory Technology	DDR4 SDRAM
Maximum Memory	1 TB
RAID Supported	Yes
Controller Type	12Gb/s SASSerial ATA/600
Ethernet Technology	10 Gigabit EthernetFast Ethernet
Number of Total Expansion Bays	24
Number of 3.5" Bays	24
Number of Total Expansion Slots	7
Number of PCI Express x8 Slots	6
Number of PCI Express x16 Slots	1
Total Number of USB Ports	5
Number of USB 3.0 Ports	2
Height	7"
Width	17.2"
Depth	26.5"
Color	Black
Rack Height	4U
Form Factor	Rack-mountable
Weight (Approximate)	54.90 lb
