Supermicro SuperServer (Black) SYS-1028TP-DTFR 1028TP-DTFR

Supermicro's New Generation X10 Haswell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	1028TP-DTFR
Product Name	SuperServer 1028TP-DTFR (Black)
Product Line	SuperServer
Manufacturer Part Number	SYS-1028TP-DTFR
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer 1028TP-DTFR (Black) 2 x Super X10DRT-PIBF Motherboards 1 x 1U Chassis 1 x 1U 8-Port 2-Node 12Gbps Backplane for 4x2.5 2 x Backplane adapter card; 6SATA ports,RoHS/REACH,PBF 1 x CAUTION LABEL FOR REDUNDANT PWR SYSTEMS 2 x RoHS/REACH,PBF 2 x 1U Passive Front CPU Heat Sink w/ a Middle Air Channel for X9, X10 2U Twin^2+ and Twin Pro^2 Series Servers 2 x 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB 2 x 1000W Redundant Titanium Level (96%) Power Supplies
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612
Number of Nodes	2
Number of Processors Supported	2
Processor Socket	Socket LGA 2011-v3
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	4
Total Number of USB Ports	2
Number of USB 3.0 Ports	2
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	1 kW
Input Voltage	120 V AC230 V AC
Number of Internal 2.5" Bays	4
Number of Total Expansion Bays	4
Number of Total Expansion Slots	2
Number of PCI Express x16 Slots	2
Number of Total Memory Slots	16
Memory Standard	DDR4-2133/PC4-17000
Memory Technology	DDR4 SDRAM
Maximum Memory	1 TB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	Gigabit Ethernet
Height	1.7"
Width	19.1"
Depth	29.5"
Color	Black
Rack Height	1U
Form Factor	Rack-mountable
Weight (Approximate)	33.50 lb
Limited Warranty	1 Year
