Supermicro SuperServer (Black) SYS-1028TR-T 1028TR-T

Supermicro's New Generation X10 Haswell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	1028TR-T
Product Name	SuperServer 1028TR-T (Black)
Manufacturer Part Number	SYS-1028TR-T
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer 1028TR-T (Black) 2 x Super X10DRT-L Motherboard 1 x 1U Chassis 2 x BPN-SAS-809T-O-P 2 x 45cm SATA cable S-RA 30AWG,RoHS/REACH 4 x 55cm SATA cable S-RA 30AWG 2 x 55cm 30AWG SATA S-S cable 2 x 8 pin to 8 pin round SGPIO cable, 61.5cm, 28AWG, pinout 1-1,RoHS/REACH 2 x ,RoHS/REACH,PBF 2 x 1U Passive Custom Rear CPU Heat Sink for X9, X10 1U Twin, 2U Twin^2 8-DIMM per Node Series Servers 2 x 1U Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB 1 x 1U 1000W Redundant Power Supply Titanium W/PMbus 76x365x40mm,RoHS/REACH 1 x SC813M,SC113M, DP X9DRL-EF/ X9DRL-7F/ X10DRL-i, X9/X10 mylar air shroud, 12"x10" MB,RoHS/REACH 1 x 1U I/O Shield for X9DB3/X9DBi/X9DB3-F/X9DBi-F/X10DRL-CT with EMI Gasket,RoHS/REACH
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612
Number of Nodes	2
Number of Processors Supported	2
Processor Socket	Socket LGA 2011-v3
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	10
Total Number of USB Ports	2
Number of Power Supplies Installed	1
Maximum Power Supply Wattage	1 kW
Number of Internal 2.5" Bays	4
Number of Total Expansion Bays	4
Number of Total Expansion Slots	1
Number of PCI Express x16 Slots	1
Number of Total Memory Slots	8
Memory Standard	DDR4-2133/PC4-17000
Memory Technology	DDR4 SDRAM
Maximum Memory	512 GB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	Gigabit Ethernet
Height	1.7"
Width	17.2"
Depth	27.8"
Color	Black
Rack Height	1U
Form Factor	Rack-mountable
Limited Warranty	3 Year
