Supermicro SuperServer (Black) SYS-2028TP-HTTR 2028TP-HTTR

Supermicro's New Generation X10 Haswell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	2028TP-HTTR
Product Name	SuperServer 2028TP-HTTR (Black)
Product Line	SuperServer
Manufacturer Part Number	SYS-2028TP-HTTR
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer 2028TP-HTTR (Black) 4 x Super X10DRT-PT Motherboards 1 x 2U Chassis 1 x RoHS/REACH,PBF 2U Twin Square Backplane, support 24 SAS3/SATA3 HDD (2.5") with Hot Swapping. Per node for 6 HDDs. PWM fan control, HDD spin up and failure LED supported. 4 x Backplan adapter card; 6SATA ports,RoHS/REACH,PBF 4 x RoHS/REACH,PBF 4 x 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB 4 x 1U Passive Front CPU Heat Sink w/ a Middle Air Channel for X9, X10 2U Twin^2+ and Twin Pro^2 Series Servers 2 x 2000W redundant platinum power supply
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612 Express
Number of Nodes	4
Number of Processors Supported	2
Processor Socket	Socket LGA 2011-v3
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	6
Total Number of USB Ports	2
Number of USB 3.0 Ports	2
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	2 kW
Number of Internal 2.5" Bays	6
Number of Total Expansion Bays	6
Number of Total Expansion Slots	2
Number of PCI Express x16 Slots	2
Number of Total Memory Slots	16
Memory Standard	DDR4-2133/PC4-17000
Memory Technology	DDR4 SDRAM
Maximum Memory	1 TB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	10 Gigabit EthernetFast Ethernet
Height	3.5"
Width	17.3"
Depth	28.5"
Color	Black
Rack Height	2U
Form Factor	Rack-mountable
Limited Warranty	3 Year
