Supermicro SuperServer SYS- (Black) SYS-5038MR-H8TRF 5038MR-H8TRF

The Supermicro MicroCloud modular server system provides the high density, performance, efficiency and cost savings required for today's demanding server deployments. The 12/8 modular server nodes are conveniently integrated into a compact 3U chassis that is only 29.5/23.2 inches deep, saving over 72% of rack space when compared to traditional 1U servers optimized for the best performance per rack. The cable-less, hot-pluggable server nodes operate independently. Each node provides up to 128GB of DDR3-1600/1333MHz of ECC LR/RDIMM memory, one PCI-E 3.0 x8 expansion slot for low-profile add-on card, and two 3.5" or four 2.5" SATA 3.0 (6Gbps) hard disk drives. The MicroCloud system utilizes redundant Platinum Level (94%) high-efficiency power supplies and sophisticated cooling zone controls for a Green energy profile. Each node is powered by processors from either the newest Intel® Xeon® E3-1200v2 & E3-1200 v3 families (5037MC and 5038ML models) or E5-2600 family up to 130W TDP; or the 8/4-Core AMD Opteron™ 3000 series

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	5038MR-H8TRF
Product Name	SuperServer SYS-5038MR-H8TRF (Black)
Product Line	SuperServer
Manufacturer Part Number	SYS-5038MR-H8TRF
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer SYS-5038MR-H8TRF (Black) 8 x Super X10SRD-F Motherboard 1 x 3U Chassis 8 x AOC-CGP-I2-O-P 8 x Mylar air shroud portion-1 for SC938, X9SRD 1 x Backplane for SC938, 16x 3.5" SAS/SATA 1 x 11.5CM KVM/SUVI 36 PIN TO 9 PIN/15 PIN 2USB, 30/28AWG 1 x CAUTION LABEL FOR REDUNDANT PWR SYSTEMS 8 x RSC-RR1U-E8 (Rev 4.00) 8 x Customized Passive CPU Heat Sink for Micro Cloud Series Servers 2 x 1620W REDUNDANT POWER MODULE
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612
Number of Nodes	8
Number of Processors Supported	1
Processor Socket	Socket LGA 2011-v3
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	2
Total Number of USB Ports	2
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	1.62 kW
Input Voltage	120 V AC230 V AC
Number of Total Memory Slots	4
Memory Standard	DDR4-2133/PC4-17000
Memory Technology	DDR4 SDRAM
Maximum Memory	256 GB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	Gigabit Ethernet
Number of Total Expansion Bays	2
Number of 3.5" Bays	2
Number of Total Expansion Slots	1
Number of PCI Express x8 Slots	1
Height	5.2"
Width	17.3"
Depth	23.2"
Color	Black
Rack Height	3U
Form Factor	Rack-mountable
Weight (Approximate)	62.19 lb
Limited Warranty	3 Year
