Supermicro SuperServer (Black) SYS-6017R-M7UF 6017R-M7UF

Designed for optimal performance, the dual-processor SuperServers support the QPI (8.0GT/s) format Xeon® processor E5-2600 or E5-2600 v2 family in a high-density 1U form-factor. These SuperServers are ideal for network infrastructure, front-end enterprise, and minimal-downtime cluster server systems.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	6017R-M7UF
Product Name	SuperServer 6017R-M7UF (Black)
Product Line	SuperServer
Manufacturer Part Number	SYS-6017R-M7UF
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer 6017R-M7UF (Black) 1x Super X9DRL-7F Motherboard 1x 1U Chassis 1x BPN-SAS-815TQ-O-P 1x 8 pin to 8 pin ribbon SGPIO cable with tube , 40cm, PBF 1x SET OF 4 SATA 56/45.5/35/23CM ROUND S-RA. 26AWG 1x RSC-RR1U-E8 (Rev 4.00) 2x 1U Passive Custom CPU Heat Sink for X9DRL Motherboard,RoHS,PBF 1x 1U 400W Redundant Short Depth Power Supply
Chipset Manufacturer	Intel
Chipset Model	C602J
Number of Processors Supported	2
QuickPath Interconnect Supported	Yes
Processor Socket	Socket R LGA-2011
Processor Supported	Xeon
Graphics Controller Manufacturer	Matrox
Graphics Controller Model	G200eW
Number of SATA Interfaces	6
Number of SAS Interfaces	8
VGA	Yes
Total Number of USB Ports	7
RAID Supported	Yes
Controller Type	Serial ATA/600Serial ATA/3006Gb/s SAS
Ethernet Technology	Fast EthernetGigabit Ethernet
Number of Total Expansion Bays	4
Number of 3.5" Bays	4
Number of Total Expansion Slots	1
Memory Standard	DDR3-1866/PC3-15000
Memory Technology	DDR3 SDRAM
Maximum Memory	512 GB
Height	1.7"
Width	17.2"
Depth	19.8"
Color	Black
Rack Height	1U
Form Factor	Rack-mountable
Limited Warranty	3 Year
