Supermicro SuperServer (Silver) SYS-6018R-MD 6018R-MD

Supermicro's New Generation X10 Haswell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	6018R-MD
Product Name	SuperServer 6018R-MD (Silver)
Product Line	SuperServer
Manufacturer Part Number	SYS-6018R-MD
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer 6018R-MD (Silver) 1 x Super X10DRD-L Motherboard 1 x 1U Chassis 1 x Y split , big 4 pin to two RA SATA power extension 15cm, 18AWG 2 x 81CM 30AWG SATA S-S cable 1 x Optional shorter 1U riser card bracekt for X9DRL-7F/EF 1 x 3.5in fixed HDD tray for SC513,514,515,812L,812U,523,HF,RoHS/REACH 1 x Dual 2.5" fixed HDD bracket for SC514,515,HF,RoHS/REACH 1 x SYS-6018R-MD, QRG,HF,RoHS/REACH 1 x RSC-RR1U-E8 (Rev 4.00) 2 x 1U Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB 1 x 1U 500W Multi-output, Platinum level w/ PMbus 24pin, W100xL180xH40mm,RoHS/REACH 5 x 40x40x56 mm 13K-11K RPM Counter-rotating Fan
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612
Number of Processors Supported	2
Processor Socket	Socket LGA 2011-v3
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	6
Total Number of USB Ports	7
Number of Power Supplies Installed	1
Maximum Power Supply Wattage	500 W
Input Voltage	120 V AC230 V AC
Number of Total Memory Slots	8
Memory Standard	DDR4-2133/PC4-17000
Memory Technology	DDR4 SDRAM
Maximum Memory	512 GB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	Gigabit Ethernet
Number of Total Expansion Slots	1
Number of PCI Express x8 Slots	1
Height	1.7"
Width	17.2"
Depth	16.9"
Color	Silver
Rack Height	1U
Form Factor	Rack-mountable
Limited Warranty	3 Year
