Supermicro SuperServer (Black) SYS-6018R-TD 6018R-TD

Supermicro SuperServer (Black) SYS-6018R-TD 6018R-TD
Price $1,241.33
Manufacturer: Supermicro
Mfg Number: SYS-6018R-TD
Model: 6018R-TD
Condition: New
Supermicro's New Generation X10 Haswell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.
Product TypeBarebone System
Brand NameSupermicro
ManufacturerSupermicro Computer, Inc
Product Model6018R-TD
Product NameSuperServer 6018R-TD (Black)
Product LineSuperServer
Manufacturer Part NumberSYS-6018R-TD
Manufacturer Website Addresshttp://www.supermicro.com
Green CompliantYes
Green Compliance Certificate/AuthorityRoHS
Package Contents
  • SuperServer 6018R-TD (Black)
  • 1 x Super X10DRD-L Motherboard
  • 1 x 1U Chassis
  • 1 x Sup 4x SAS/SATA;No SES-II; SATA con
  • 1 x SET OF 4 SATA 70/59/48/38CM ROUND S-RA, 26AWG
  • 1 x Optional shorter 1U riser card bracekt for X9DRL-7F/EF
  • 1 x 4028mm 13K RPM 4-PIN PWM FAN for SC813MF, SC113M
  • 1 x SYS-6018R-TD, QRG,HF,RoHS/REACH
  • 1 x 1U I/O shield for X10 and X9 Server MB with 5X5mm vent hole and EMI Gasket,RoHS/REACH,PBF
  • 1 x RSC-RR1U-E8 (Rev 4.00)
  • 2 x 1U Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB
  • 2 x 97Lx94Wx37H mm 5K RPM SC813 Rev. M Chassis Middle Cooling Blower
  • 1 x Optional fan tray for one 40x28mm fan in SC813T/SC813LT-single PWS (Fan tray only)
  • 1 x 440W/480W Platinum Power Supply
64-bit ProcessingYes
Chipset ManufacturerIntel
Chipset ModelC612
Number of Processors Supported2
Processor SocketSocket LGA 2011-v3
Processor SupportedXeon
Graphics Controller ManufacturerASPEED
Graphics Controller ModelAST2400
Number of SATA Interfaces6
Total Number of USB Ports7
Number of Power Supplies Installed1
Maximum Power Supply Wattage480 W
Input Voltage120 V AC230 V AC
Number of Total Memory Slots8
Memory StandardDDR4-2133/PC4-17000
Memory TechnologyDDR4 SDRAM
Maximum Memory512 GB
RAID SupportedYes
Controller TypeSerial ATA/600
Ethernet TechnologyGigabit Ethernet
Number of 3.5" Bays4
Number of Total Expansion Slots1
Number of PCI Express x8 Slots1
Rack Height1U
Form FactorRack-mountable
Limited Warranty3 Year
