Supermicro SuperServer (Black) SYS-6028R-T 6028R-T

Supermicro's New Generation X10 Haswell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	6028R-T
Product Name	SuperServer 6028R-T (Black)
Product Line	SuperServer
Manufacturer Part Number	SYS-6028R-T
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer 6028R-T (Black) 1 x Super X10DRi Motherboard 1 x 1U Chassis 1 x 823 SAS TQ BACKPLANE W/AMI 9072 3 x 29cm 30AWG SATA S-S cable 3 x 55cm 30AWG SATA S-S cable 2 x 8 pin to 8 pin round SGPIO cable, 40cm, 28AWG, pinout 1-1,RoHS/REACH 2 x 2U Passive CPU Heat Sink for X9, X10 Generation Systems Equipped w/ a Narrow ILM MB 1 x 2U 650W Multi Output Power Supply High Efficiency 1 x SC823/822 Intel DP X9, X8,H8 PC universal air shroud,12x13MB 1 x BLACK 5.25 DUMMY TRAY W/ RAIL IN SC822 6 x Black Hot-swap 3.5inch HDD Tray (w/o logo)
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612 Express
Number of Processors Supported	2
Processor Socket	Socket R3 (LGA2011-3)
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	10
Total Number of USB Ports	11
Number of USB 3.0 Ports	4
Number of Power Supplies Installed	1
Maximum Power Supply Wattage	650 W
Input Voltage	120 V AC230 V AC
Number of Total Memory Slots	16
Memory Standard	DDR4-2133/PC4-17000
Memory Technology	DDR4 SDRAM
Maximum Memory	1 TB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	Gigabit EthernetFast Ethernet
Number of Total Expansion Bays	6
Number of 3.5" Bays	6
Number of Total Expansion Slots	6
Number of PCI Express x8 Slots	3
Number of PCI Express x16 Slots	3
Height	3.5"
Width	16.8"
Depth	25.6"
Color	Black
Rack Height	2U
Form Factor	Rack-mountable
Limited Warranty	3 Year
