Supermicro SuperServer (Black) SYS-6028TR-DTR 6028TR-DTR

Supermicro's New Generation X10 Haswell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	6028TR-DTR
Product Name	SuperServer 6028TR-DTR (Black)
Product Line	SuperServer
Manufacturer Part Number	SYS-6028TR-DTR
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer 6028TR-DTR (Black) 2 x Super X10DRT-H Motherboard 1 x 2U Chassis 2 x SC827HD air shroud - Bigger size to support 135W CPU X9DRT-HF 1 x Sup 6x3.5� SATA hdd; hot swap 2 x 6-PORT SATA ADAPTER FOR TWIN 4 x 21cm 30AWG SATA S-S cable 1 x CAUTION LABEL FOR REDUNDANT PWR SYSTEMS 1 x MNL-SYS-6028TR-DTR/D72R,QRG 2 x 2U RHS Riser Card with 3 PCI-E x8 for X9DRT-HF Twin MBs 2 x 2U Passive CPU Heat Sink for X9, X10 Generation Systems Equipped w/ a Narrow ILM MB 2 x 2U Passive Rear CPU Heat Sink for X9, X10 2U Twin 8-DIMM per Node Series Servers 2 x 1U 1280W, redundant single output power supply
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612
Number of Nodes	2
Number of Processors Supported	2
Processor Socket	Socket LGA 2011-v3
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	8
Total Number of USB Ports	2
Number of USB 3.0 Ports	2
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	1.28 kW
Number of Total Memory Slots	8
Memory Standard	DDR4-2133/PC4-17000
Memory Technology	DDR4 SDRAM
Maximum Memory	512 GB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	Gigabit EthernetFast Ethernet
Number of Total Expansion Bays	6
Number of 3.5" Bays	6
Number of Total Expansion Slots	3
Number of PCI Express x8 Slots	3
Height	3.5"
Width	17.3"
Depth	28.5"
Color	Black
Rack Height	2U
Form Factor	Rack-mountable
Weight (Approximate)	82.45 lb
Limited Warranty	3 Year
