Supermicro SuperServer (Black) SYS-8028B-TR4F 8028B-TR4F

2 TB DDR4 SDRAM - Serial ATA/600 RAID Supported Controller - ASPEED AST2400 Integrated - 6 x Total Bays - 6 3.5" Bay(s) - 4 x Total Expansion Slots - Processor Support (Xeon) - Gigabit Ethernet - 2 x 1.40 kW

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	8028B-TR4F
Product Name	SuperServer 8028B-TR4F (Black)
Product Line	SuperServer
Manufacturer Part Number	SYS-8028B-TR4F
Manufacturer Website Address	http://www.supermicro.com
Green Compliant	Yes
Green Compliance Certificate/Authority	RoHS
Package Contents	SuperServer 8028B-TR4F (Black) 1 x Super X10QBL-4 Motherboard 1 x CSE-828TQ-R1K43LPB 2U Chassis 1 x Mylar air shroud for SC828 (X10QBL-(CT)),RoHS/REACH 1 x Sup 6x SAS/SATA hdd; SATA con 2 x 48CM SATA ROUND S-RA PBF.26AWG 2 x 55CM SATA ROUND S-RA PBF 26AWG 2 x 8 pin to 8 pin ribbon SGPIO cable with tube, 60cm, PBF 2 x 65CM SATA ROUND S-RA PBF. 26AWG 1 x CAUTION LABEL FOR REDUNDANT PWR SYSTEMS 1 x Standard I/O shield for X10QBL-CT with EMI Gasket,RoHS/REACH 4 x 2U Passive CPU Heat Sink for X9, X10 Generation Systems Equipped w/ a Narrow ILM MB 2 x 1400W redundant digital power supply
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C602J
Number of Processors Supported	4
Processor Socket	Socket R LGA-2011
Processor Supported	Xeon
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	6
Total Number of USB Ports	3
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	1.40 kW
Input Voltage	120 V AC230 V AC
Number of Total Memory Slots	32
Memory Technology	DDR4 SDRAM
Maximum Memory	2 TB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	Gigabit Ethernet
Number of Total Expansion Bays	6
Number of 3.5" Bays	6
Number of Total Expansion Slots	4
Number of PCI Express x8 Slots	2
Number of PCI Express x16 Slots	2
Height	3.5"
Width	17.2"
Depth	27.9"
Color	Black
Rack Height	2U
Form Factor	Rack-mountable
Weight (Approximate)	40 lb
Limited Warranty	3 Year
