Supermicro Server Motherboard MBD-X10DRI-T-B X10DRi-T

Xeon® E5 Family BOARDS / Socket R3 (LGA 2011) Introducing Supermicro's latest generation of dual processor motherboard technology based on Intel's E5-2600 v3 Haswell processor. Supermicro's X10 motherboards are specifically designed to meet the demanding needs of today's complex computational workloads. Feature rich and highly expandable, our X10 motherboards provide the latest advanced integrated and expandable storage and networking technologies. Features like lightning fast DDR4 memory, NVMe/SAS3/SATA3 storage interfaces, 1G/10GBASE-T, 10G SFP+, 40GbE, and Infiniband QDR/FDR. With its unprecedented set of features, each X10 motherboard is specifically tailored to provide optimal performance while helping to reduce deployment and operational costs over the lifespan of the product.

Product Type	Server Motherboard
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	X10DRi-T
Product Name	X10DRi-T Server Motherboard
Package Type	Bulk
Manufacturer Part Number	MBD-X10DRI-T-B
Manufacturer Website Address	http://www.supermicro.com
Packaged Quantity	1
Chipset Manufacturer	Intel
Processor Socket	Socket LGA 2011-v3
Processor Supported	Xeon
Total Processor Supported	2
Number of Memory Slots	16
Memory Form Factor	DIMM RDIMM LRDIMM
Memory Speed Supported	2133 MHz 1866 MHz 1600 MHz
Memory Standard	DDR4-2133/PC4-17000 DDR4-1866/PC4-14900 DDR4-1600/PC4-12800
Memory Technology	DDR4 SDRAM
Maximum Memory	1 TB
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Onboard Video	On-board Video Chipset
Gigabit Ethernet	Yes
Number of SATA Interfaces	10
Total Number of Onboard USB Ports	7
Number of Onboard USB 3.0 Ports	3
RAID Supported	Yes
RAID Levels	0 1 5 10
Controller Type	Serial ATA/600
Number of Total Expansion Slots	6
Number of PCI Express x8 Slots	3
Number of PCI Express x16 Slots	3
Total Number of PCI Express Slots	6
VGA	Yes
Total Number of USB Ports	4
Number of USB 3.0 Ports	2
Width	12"
Depth	13"
Form Factor	Extended ATX
