Supermicro Server Motherboard MBD-X12SDV-8C-SPT4F-O X12SDV-8C-SPT4F

Supermicro motherboards support the latest generation Intel and AMD processors, memories and offer the most advanced technologies in the IT field - NVMe, M.2, 10GbE network ports. Thanks to their high scalability and a wide choice of form factors, the boards can fulfill the needs of even the most demanding customers. Supermicro offers the broadest selection of servers designed for industrial use, which is reflected in the overall quality of the boards. Materials that guarantee a long lifespan are used for manufacturing Supermicro motherboards, thanks to which a minimal failure rate is achieved. Supermicro motherboards go through a generational exchange approximately once every seven years, which guarantees long support by the manufacturer. Each Supermicro motherboard also allows free installation of specialized software for basic system monitoring.The purchase of NBD warranty of your own choice is a matter of course, which minimizes service outages even in cases that cannot be predicted. Contact our sales department for more information. Standard NBD warranties are offered for 3 or 5 years.

HDMI	No
DVI	No
VGA	Yes
Number of Network (RJ-45) Ports	4
Total Number of USB Ports	2
Product Type	Server Motherboard
Manufacturer Part Number	MBDX12SDV8CSPT4FO
Manufacturer Website Address	http://www.supermicro.com
Packaged Quantity	1
Manufacturer	Supermicro Computer, Inc
Product Model	X12SDV-8C-SPT4F
Product Name	X12SDV-8C-SPT4F Server Motherboard
Package Type	Retail
Brand Name	Supermicro
Number of PCI Express x4 Slots	1
Number of PCI Express x8 Slots	1
PCI Express Standard	PCI Express 3.0 PCI Express 4.0
Total Number of PCI Express Slots	2
Total Number of Expansion Slots	2
Error Checking	ECC
Maximum Memory Supported	128 GB
Memory Technology	DDR4 SDRAM
Number of Memory Slots	2
Memory Form Factor	DIMM RDIMM UDIMM
Memory Speed Supported	2666 MHz 2400 MHz
Package Contents	X12SDV-8C-SPT4F Server Motherboard 1 x 6CM ATX Power Signal Cable 1 x COM Cable 20cm 1 x Standard I/O Shield 1 x 50CM OCuLink to 4x SATA Cable 1 x 55CM OCuLink to U.2 Cable with Molex Power Header 1 x Motherboard Quick Reference Guide
Environmental Compliance	Taiwan Restriction of Hazardous Substances (Taiwan RoHS) Restriction of Hazardous Substances (RoHS)
Gigabit Ethernet	Yes
10Gigabit Ethernet	Yes
Weight (Approximate)	2.20 lb
Form Factor	Mini ITX
Width	6.8"
Depth	6.8"
Processor Supported	Xeon D
Total Processor Supported	1
Processor Socket	Socket BGA-2227
Chipset Manufacturer	Intel
Processor Generation Supported	1st Gen
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2600
Onboard Video	CPU Dependent Video
Limited Warranty	36 Month
RAID Levels	0 1 5 10
Controller Type	Serial ATA/600
RAID Supported	Yes
Number of SATA Interfaces	4
Total Number of Onboard USB Ports	2
Number of M.2 Interfaces	1
