Supermicro Dual-Socket Blade SBI-6129P-C3N

Supermicro Dual-Socket Blade SBI-6129P-C3N
Price $1,421.72
Manufacturer: Supermicro
Mfg Number: SBI-6129P-C3N
SKU:
Condition: New
UPC: 672042316304
Accessories
Description
Supermicro SuperBlade® The innovative and feature-rich SuperBlade® enhances system computing density by housing multiple blade servers in a single enclosure. Applying Supermicro's application-optimized engineering philosophy and leveraging years of rackmount server design experience, SuperBlade® modules deliver true server functionality and boast simplified access and maintenance with front-loading nodes. Each node includes up to four 2nd generation Intel® Xeon® Scalable Processors with up to 12TB DDR4-2933MHz ECC memory in 48 DIMM slots with support for Intel® Optane™ DC Persistent Memory, 205W per socket, NVMe/SAS3 HDD support, optional 100G EDR InfiniBand/Intel Omni-Path or 25G mezzanine HCA, optional PCI-E 3.0 expansion card, support for up to 8 NVMe or 4 SATA3/SAS3 hard drives, and 100-240VAC redundant Titanium Level high-efficiency (96%), N+1 power supplies. Each blade server fits into existing Supermicro blade enclosures, thus protecting initial investments and offering smooth product upgrades and migrations.
Specifications
Product Type Barebone System
Brand Name Supermicro
Manufacturer Supermicro Computer, Inc
Product Model SBI-6129P-C3N
Product Name Dual-Socket Blade SBI-6129P-C3N
Product Line SuperBlade
Manufacturer Part Number SBI-6129P-C3N
Manufacturer Website Address http://www.supermicro.com
Environmentally Friendly Yes
Environmental Certification RoHS
Package Contents
  • Dual-Socket Blade SBI-6129P-C3N
  • 1 x Super B11DPE Motherboard
  • 1 x 6U 10 SuperBlade DP Blade chassis
  • 1 x AOM-BPNIO-SC, I/O module for uBlade,RoHS
  • 2 x Black 2.5" NVMe Hard Drive Tray, orange button
  • 1 x Black gen 4 hot swap 2.5" HDD tray for Twin Blade
  • 4 x 6U 10 SuperBlade B11DPE Processor Tray Air Shroud
64-bit Processing Yes
Chipset Manufacturer Intel
Chipset Model C622
Number of Processors Supported 2
Processor Socket Socket P LGA-3647
Processor Supported Xeon Silver Xeon Gold Xeon Platinum Xeon Bronze
Graphics Controller Manufacturer ASPEED
Graphics Controller Model AST2500
Number of Total Memory Slots 24
Intel Optane Memory Ready Yes
Memory Standard DDR4-2933/PC4-23466
Memory Technology DDR4 SDRAM
Maximum Memory 6 TB
RAID Supported Yes
Controller Type Serial ATA/600 12Gb/s SAS
Ethernet Technology 10 Gigabit Ethernet
Number of Total Expansion Bays 3
Height 9.8"
Width 1.8"
Depth 23.5"
Color Black
Form Factor Blade
Weight (Approximate) 12.60 lb
Limited Warranty 1 Year
