Supermicro SuperServer (Black) SSG-5049P-E1CTR36L 5049P-E1CTR36L

New-generation X11 Supermicro SuperStorage systems support node-based deployment strategies where CPU and HDD capacity scale together, or deployments can be expanded using JBODs for improved economy. Low-latency SSD applications, large media files requiring massive capacity and enterprise workloads looking for the highest performance will benefit from Supermicro's SAS 3.0 (12 Gbps) support which provides low-latency and maximum data bandwidth. The Supermicro SuperStorage systems offer a no-compromise storage platform with flexible market entry points from 2U, 3U, and 4U form factors using 2.5" or 3.5" SSDs/HDDs. SuperStorage servers support up to: 1TB 3DS ECC LRDIMM or 256GB ECC RDIMM memory, PCI-E 3.0 slots, NVMe, flexible networking options such as 10G SFP+, 10GBase-T LAN ports and IPMI 2.0 and KVM with dedicated LAN, and have support for the latest Intel® Xeon® Scalable processors. Supermicro SuperStorage solutions present a number of key benefits to customers working with CPU-Intensive Storage, Virtual Storage, Single-Instance Storage and Data Deduplication, Data Replication and Business Continuity, and Virtual Tape Library customer environments.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	5049P-E1CTR36L
Product Name	SuperServer 5049P-E1CTR36L (Black)
Product Line	SuperStorage
Manufacturer Part Number	SSG-5049P-E1CTR36L
Manufacturer Website Address	http://www.supermicro.com
Environmentally Friendly	Yes
Environmental Certification	RoHS
Package Contents	SuperServer 5049P-E1CTR36L (Black) 1 x Super X11SPH-nCTF Motherboard 1 x 4U Chassis 1 x 8-port Mini SAS HD Int-to-Ext cable adapter w/ LP bracket,HF,RoHS/REACH 1 x 12-port 2U SAS3 12Gbps single-expander backplane, support up to 12x 3.5-inch SAS3/SATA3 HDD/SSD 1 x 24-port 4U SAS3 12Gbps single-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD 4 x 4 pin to 4 pin fan extension cord, for PWM fan. 23cm. 24AWG 6 x MINI SAS HD,12G,INT,80CM,30AWG 1 x Standard I/O Shield for X11SPM-TF with EMI Gasket 1 x 5049P-E1CR36L Quick Reference Guide 1 x 2U Passive CPU Heat Sink for X11 Purley Platform Equipped with a Narrow Retention Mechanism 2 x AC-DC 1200W, Titanium Level, Redundancy, 1U, PMBUS 1.2, +12V/+5Vsb, 360x76x40 mm,HF,RoHS/REACH 7 x 80x80x38 mm, 10.5K RPM, Optional Middle Cooling Fan for X10 2U Ultra and HFT Series Servers,RoHS/REACH
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C622
Number of Processors Supported	1
Processor Socket	Socket P LGA-3647
Processor Supported	Xeon PlatinumXeon GoldXeon SilverXeon Bronze
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2500
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	1200 W
Input Voltage	120 V AC230 V AC
Number of Internal 2.5" Bays	6
Number of Total Expansion Bays	42
Number of 3.5" Bays	36
Number of Total Expansion Slots	4
Number of PCI Express x8 Slots	3
Number of PCI Express x16 Slots	1
Number of Total Memory Slots	8
Memory Standard	DDR4-2666/PC4-21300
Memory Technology	DDR4 SDRAM
Maximum Memory	1 TB
RAID Supported	Yes
Controller Type	Serial ATA/60012Gb/s SAS
Ethernet Technology	10 Gigabit Ethernet
Total Number of USB Ports	4
Number of USB 3.0 Ports	2
Height	7"
Width	17.2"
Depth	27.5"
Color	Black
Rack Height	4U
Form Factor	Rack-mountable
Weight (Approximate)	65.50 lb
Limited Warranty	3 Year
