Supermicro SuperServer (Black) SYS-1018R-WR 1018R-WR

The Supermicro WIO serverboard product family offers a range of new generation X11 motherboards which are designed to deliver a wide range of I/O options for accelerated computing. Users can optimize the storage and networking alternatives to accelerate performance, increase efficiency and find the perfect fit for their applications. In addition to enabling customizable configurations and optimization for multiple application requirements, Supermicro WIO SuperServers also provide attractive cost advantages and investment protection. The Supermicro WIO SuperServer® product family supports up to: 1.5TB ECC 3DS LRDIMM or RDIMM DDR4-2666MHz memory in 12 DIMM slots, 3/6 Add-on Cards in 1U/2U, 10 SATA 3.0 (6Gbps) ports with Intel® C620 controller, hot-swap 2.5" or 3.5" drive bays, SATA3 and NVMe hybrid ports, optional NVMe drives, LAN options up to 2x 10GBase-T or 2 GbE ports, redundant Platinum Level (95%) power supplies, integrated IPMI 2.0 with KVM over dedicated LAN, and dual or single Intel® Xeon® Scalable Processor Family up to 28 cores and 205W TDP. Supermicro WIO serverboards are optimized for general purpose, ERP/MRP, and network and security appliance applications and are compatible with the following Supermicro chassis: SC113TQ, SC116TQ, SC213A, SC825TQ, and SC815TQ.

Number of SATA Interfaces	10
Total Number of USB Ports	6
Number of USB 3.0 Ports	4
Controller Type	Serial ATA/600
RAID Supported	Yes
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Product Type	Barebone System
Manufacturer Part Number	SYS-1018R-WR
Manufacturer Website Address	http://www.supermicro.com
Manufacturer	Supermicro Computer, Inc
Product Model	1018R-WR
Product Name	SuperServer 1018R-WR (Black)
Product Line	SuperServer
Brand Name	Supermicro
Number of Internal 2.5" Bays	2
Number of Total Expansion Bays	2
Number of Total Expansion Slots	3
Number of PCI Express x8 Slots	1
Number of PCI Express x16 Slots	2
Maximum Memory Supported	1 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2400/PC4-19200
Number of Total Memory Slots	8
Package Contents	SuperServer 1018R-WR (Black) 1 x Super X10SRW-F Motherboard 1 x 1U Chassis 1 x SC811/SC512L/SC512F/SC813M/SC113M/SC513L-410B/SC513L-420B/SC513F, UP X9SRE/I, X9 Mylar Air Shroud, 12"x9.6" MB 1 x Y split , big 4 pin to two RA SATA power extension 15cm, 18AWG 1 x SATA,INT,ROUND,ST-RA,48CM,26AWG 1 x CAUTION LABEL FOR REDUNDANT PWR SYSTEMS 1 x X10SRW-F, CSE-514-R407W 1 x 1U LHS WIO Riser card with two PCI-E x16 slots 1 x 1U RHS WIO Riser card with one PCI-E x8 slot 1 x 1U Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB 2 x AC and DC 240V Input, 400W, Platinum Level, Redundancy power supply meet PMBus Revision 1.2 requirement,RoHS/REACH 4 x 40x40x56 mm 13K-11K RPM Counter-rotating Fan,RoHS/REACH 40x56 4Pin PWM, Primary for SC815, Secondary for SC818, 825M
Environmentally Friendly	Yes
Environmental Certification	RoHS
Ethernet Technology	Gigabit Ethernet
Weight (Approximate)	15.50 lb
Form Factor	Rack-mountable
Rack Height	1U
Height	1.7"
Width	17.2"
Depth	16.9"
Product Color	Black
Input Voltage	120 V AC 230 V AC
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	400 W
Limited Warranty	3 Year
Processor Supported	Xeon
Processor Socket	Socket R3 LGA-2011
64-bit Processing	Yes
Number of Processors Supported	1
Chipset Manufacturer	Intel
Chipset Model	C612
