Supermicro SuperServer (Black) SYS-2028R-TXR 2028R-TXR

Supermicro's New Generation X10 Haswell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	2028R-TXR
Product Name	SuperServer 2028R-TXR (Black)
Product Line	SuperServer
Manufacturer Part Number	SYS-2028R-TXR
Manufacturer Website Address	http://www.supermicro.com
Environmentally Friendly	Yes
Environmental Certification	RoHS
Package Contents	SuperServer 2028R-TXR (Black) 1 x Super X10DRX Motherboard 1 x 2U Chassis 1 x 16-port 2U SAS3 12Gbps direct-attached backplane, support up to 16x 2.5-inch SAS3/SATA3 HDD/SSD 2 x Cross-over mini SAS HD to 4 SATA w/SB, S. 55cm. 30AWG,RoHS/REACH 1 x CAUTION LABEL FOR REDUNDANT PWR SYSTEMS 1 x SYS-2028R-TXR Quick Reference Guide 1 x STD I/O shield for X9 socket R server MB with Gasket. 2 x 2U Passive CPU Heat Sink for X9, X10 Generation Systems Equipped w/ a Narrow ILM MB 2 x 1U 1000W Redundant Power Supply Titanium, 38X40X360mm length
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C612 Express
Number of Processors Supported	2
Processor Socket	Socket LGA 2011-v3
Processor Supported	Xeon
Number of External 5.25" Bays	1
Number of Internal 2.5" Bays	16
Number of Total Expansion Bays	17
Number of Total Expansion Slots	11
Number of PCI Express x8 Slots	11
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	8
Total Number of USB Ports	4
Number of USB 3.0 Ports	2
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	1 kW
Input Voltage	120 V AC230 V AC
Number of Total Memory Slots	16
Memory Standard	DDR4-2400/PC4-19200
Memory Technology	DDR4 SDRAM
Maximum Memory	2 TB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	Gigabit Ethernet
Height	3.5"
Width	17.2"
Depth	27.8"
Color	Black
Rack Height	2U
Form Factor	Rack-mountable
Weight (Approximate)	36 lb
Limited Warranty	3 Year
