Supermicro SuperServer (Black) SYS-5019S-W4TR 5019S-W4TR

Built to deliver long lifespan performance for the latest in embedded, industrial, and security applications, Supermicro uni-processor 1U rack servers and the newest Intel Xeon E3-1200 v6 family processors enable the best performance and efficiency available, with the highest levels of quality and reliability.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	5019S-W4TR
Product Name	SuperServer 5019S-W4TR (Black)
Product Line	SuperServer
Manufacturer Website Address	http://www.supermicro.com
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C236
Number of Processors Supported	1
Processor Socket	Socket H4 LGA-1151
Processor Supported	Xeon Core i3 Celeron Pentium
Number of External 5.25" Bays	1
Number of Total Expansion Bays	5
Number of 3.5" Bays	4
Number of Total Expansion Slots	1
Number of PCI Express x16 Slots	1
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2400
Number of SATA Interfaces	4
Total Number of USB Ports	4
Number of USB 3.0 Ports	2
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	500 W
Input Voltage	120 V AC 230 V AC
Number of Total Memory Slots	4
Memory Standard	DDR4-2400/PC4-19200
Memory Technology	DDR4 SDRAM
Maximum Memory	64 GB
RAID Supported	Yes
Controller Type	Serial ATA/600
Ethernet Technology	10 Gigabit Ethernet
Height	1.7"
Width	17.2"
Depth	25.6"
Color	Black
Rack Height	1U
Form Factor	Rack-mountable
Weight (Approximate)	24 lb
