Supermicro SuperServer (Black) SYS-F629P3-RTBN F629P3-RTBN

The FatTwin is available in high-density 8/4/2 hot-plug system node configurations with a choice of memory capacities, hard disk drives, power supplies, front or rear I/O, PCI and networking options and more. FatTwin support the 2nd generation Intel® Xeon® Scalable processor as well as Intel® Optane™ DC Persistent Memory. Its high efficiency, highly effective shared cooling architecture allows the FatTwin to operate in high-temperature, free-air cooled environments up to 47°C, providing considerable cost savings and improved TCO. Versatile configurations allow the FatTwin to be optimized for many different environments including Data Center, Cloud Computing, and HPC; Engineering, Research, and GPU projects; File and Storage Server deployments; and General Server and Enterprise Server applications.

Product Type	Barebone System
Brand Name	Supermicro
Manufacturer	Supermicro Computer, Inc
Product Model	F629P3-RTBN
Product Name	SuperServer F629P3-RTBN (Black)
Product Line	SuperServer
Manufacturer Part Number	SYS-F629P3-RTBN
Manufacturer Website Address	http://www.supermicro.com
Environmentally Friendly	Yes
Environmental Certification	RoHS
Package Contents	SuperServer F629P3-RTBN (Black) 4 x Super X11DPFR-SN Motherboard 1 x 4U Chassis 4 x Power distribution board for X11DPFR-S(N) 4 x 6-port Fat Twin 6Gbps hot swappable HDD backplane, support up to 6x 3.5-inch SAS/SATA HDD 4 x 2-Port Hybrid Backplane support 2 x SAS3/SATA3/NVMe Storage Devices 12 x 2x2 to 2x2 15cm power cable HF. 18AWG 4 x 20 to 20 pin cable for BPN-ADP-F418LS,7.5cm, 28AWG,RoHS/REACH,PBF 4 x PWCD,US/EU/Canada/China/Australia,IEC60320 C14 TO C13,4FT,17AWG 4 x MINI SAS HD-4 SATA,6G,INT,50CM,50CM SB,30AWG 8 x OcuLink v 1.0,INT,PCIe NVMe SSD, 37CM,34AWG 4 x 2X MINI SAS HD to 2X SATA,SB,INT,55 CM 4 x 2U Passive CPU Heat Sink with a Side Air Channel for X11 Purley Platform Equipped with a Narrow Retention Mechanism 4 x 1.5U Proprietary 50-mm Tall Passive CPU Heat Sink with a Side Air Channel for X11 Purley Platform 2U Node Twin Series Servers 4 x AC-DC 1200W, Titanium Level, Redundancy, 1U, PMBUS 1.2, +12V/+5Vsb, 360x76x40 mm,HF,RoHS/REACH
64-bit Processing	Yes
Chipset Manufacturer	Intel
Chipset Model	C621
Number of Nodes	4
Number of Processors Supported	2
Processor Socket	Socket P LGA-3647
Processor Supported	Xeon Bronze Xeon Silver Xeon Gold Xeon Platinum
Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2500
Number of SATA Interfaces	14
Total Number of USB Ports	2
Number of USB 3.0 Ports	2
Number of Power Supplies Installed	4
Maximum Power Supply Wattage	1200 W
Input Voltage	120 V AC 230 V AC
Number of Total Memory Slots	12
Intel Optane Memory Ready	Yes
Memory Standard	DDR4-2933/PC4-23466
Memory Technology	DDR4 SDRAM
Maximum Memory	3 TB
Ethernet Technology	Ethernet
Number of Total Expansion Bays	8
Number of Total Expansion Slots	2
Number of PCI Express x16 Slots	2
Height	7"
Width	17.6"
Depth	29"
Color	Black
Rack Height	4U
Form Factor	Rack-mountable
Weight (Approximate)	150 lb
Controller Type	Serial ATA/600
Limited Warranty	3 Year
