Synology Unified Controller Active-Active IP SAN for Mission-Critical Environments UC3200

Delivering reliable, highly available iSCSI services Realizing high-availability architecture in just one single chassis, the two controllers in Synology UC3200 work simultaneously and can automatically fail over to each other in the event of disaster, delivering services without any interruptions. 12 x 3.5"/2.5" HDD/SSD High-performance SAS interface drive slots with maximum 576TB raw capacity. Supporting SED (Self Encrypting Drive) to encrypt all data to hard drives, UC3200 provides upmost data security at the hardware level. Processor Armed with Intel® Xeon® D-1521 4-core 2.4 GHz processor burst up to 2.7 GHz, UC3200's dual CPUs provide enterprise-class performance of 140,000 4K random write IOPS with low latency. 4 x DDR4 memory slots 8GB ECC UDIMM, expandable up to 64GB to boost system performance. Fan Redundant, modularized fans for easy maintenance and replacement, minimizing service downtime. SATA DOM The dedicated SATA DOM isolates the operating system from the regular data stored in hard drives. Non-Transparent Bridge (NTB) Connect two controller modules at a blazingly fast speed and instantly sync memory data between the controllers to prevent cached data loss when one controller is unavailable. Works with mainstream virtualization systems Optimized for virtualization environments. Integrated with VMware vSphere® 6.5, Microsoft Hyper-V®, and VAAI to offload storage operations and optimize computational efficiency. Windows Offloaded Data Transfer (ODX) is supported to speed up data transfer and migration rates. Turn Synology UC3200 into a block-based storage component with the support of OpenStack® Cinder. Compliance with iSCSI industry standard ALUA allows hosts to identify the optimized paths to increase data transfer performance and efficiency. A system built exclusively for iSCSI DSM UC, an operating system designed to ease the learning curve, allows you to manage the two controllers from one single portal. The built-in monitor applications display the status at a glance and send prompt notifications when important events occur, so that IT administrators can stay alert to potential problems and respond in the shortest time possible. Disaster-proof your critical data Snapshot Replication is put in place with the support of Btrfs file system, offering schedulable and near-instantaneous data protection. Supporting up to 4,096 system-wide snapshots for local volumes or offsite servers, UC3200 brings application-aware snapshot protection and instant recovery of virtual machines in iSCSI LUNs in the event of a disaster. Schedulable, near-instantaneous data protection Supports up to 4,096 system-wide snapshots Instant recovery of virtual machines 5-year warranty As we're committed to improving product innovation and quality, Synology guarantees a robust and reliable data management experience with a 5-year limited warranty, providing responsive technical support and hardware replacement services to maximize your return on investment.

Number of Network (RJ-45) Ports	6
Network (RJ-45)	Yes
Number of SAS Ports (External)	2
RAID Levels	0, 1, 5, 6, 10, Basic, JBOD, RAID F1
Controller Type	Serial Attached SCSI (SAS)
Number of Controllers	2
RAID Supported	Yes
Product Type	SAN Storage System
Manufacturer Part Number	UC3200
Manufacturer Website Address	http://www.synology.com
Packaged Quantity	1
Manufacturer	Synology, Inc
Product Model	UC3200
Product Name	Unified Controller UC3200 Active-Active IP SAN for Mission-Critical Environments
Brand Name	Synology
Expansion Slot Type	PCI Express 3.0 x8
Number of Total Expansion Bays	12
Number of Total Expansion Slots	2
Number of 2.5"/3.5" Bays	12
Standard Memory	16 GB
Memory Technology	DDR4 SDRAM
Country of Origin	Taiwan
Ethernet Technology	10 Gigabit Ethernet
Weight (Approximate)	43.43 lb
Form Factor	Rack-mountable
Height	3.5"
Width	19"
Depth	28.5"
Number of Power Supplies Installed	2
Redundant Power Supply	Yes
Maximum Power Supply Wattage	500 W
Total Hard Drive Capacity Supported	192 TB
Total Solid State Drive Capacity Supported	192 TB
Number of Hard Drives Supported	12
Number of Hard Drives Installed	0
Number of Solid State Drive Supported	12
Number of Solid State Drive Installed	0
Processor Speed	2.40 GHz
Processor Type	Xeon
Processor Model	D-1521
Processor Core	Quad-core (4 Core)
Processor Manufacturer	Intel
Number of Processors Installed	2
Protocols	iSCSI Telnet SSH SNMP
Operating System	DiskStation Manager
