Transition Networks Transceiver/Media Converter SGFEB1040-230-NA SGFEB1040-230

The SGFEB Series is a stand-alone media converter that provides an interface between 10/100/1000Base-T ports and 1000Base-SX/LX ports, allowing users to integrate fiber optic cabling into 10/100/1000 copper environments. Operating at Layer 2, the data link layer, this converter not only converts copper to fiber, it also provides rate conversion allowing legacy 10/100 copper devices to connect to 1000Base-SX/LX fiber.

Number of Network (RJ-45) Ports	1
Network (RJ-45)	Yes
Total Number of Ports	1
Product Type	Transceiver/Media Converter
Manufacturer Part Number	SGFEB1040-230-NA
Manufacturer Website Address	http://www.transition.com
Manufacturer	Transition Networks, Inc
Product Model	SGFEB1040-230
Product Name	SGFEB1040-230 Transceiver/Media Converter
Product Series	SGFEB
Brand Name	Transition Networks
Expansion Slot Type	SFP (mini-GBIC)
Number of Total Expansion Slots	2
Number of SFP Slots	2
Maximum Distance Supported	328.08 ft
Media Type Supported	Twisted Pair Optical Fiber
Country of Origin	Taiwan
Network Technology	10/100/1000Base-T 1000Base-X
Ethernet Technology	Gigabit Ethernet
Weight (Approximate)	2 lb
Form Factor	Standalone Wall Mountable Rail-mountable
Height	1"
Width	4.8"
Depth	3.3"
Power Source	Power Supply
