TRENDnet 6-Port Industrial Gigabit PoE+ DIN-Rail Switch 12 - 56 V TI-PG62B

TRENDnet's TI-PG62B is a reliable IP30 unmanaged hardened DIN-rail PoE+ switch with a rugged housing rated for extreme industrial environments. It offers 4 Gigabit PoE+ ports, two dedicated SFP slots and a 12 Gbps switching capacity. Dual redundant 12 - 56 VDC power inputs and a power failure alarm relay. PoE Power A 60 - 120 W PoE+ power budget supplies up to four Power over Ethernet devices. Fault Tolerance Features dual redundant 12 - 56 VDC power inputs with output alarm relay. Industrial Hardened Design Equipped with a rugged IP30 rated housing designed to withstand a high degree of vibration, shock, protection against ESD / EMI / surge, and operate within a wide temperature range of -40 - 75° C (-40 - 167° F). Network Ports 4 x Gigabit PoE+ ports and 2 x dedicated SFP slots DIN-Rail / Wall Mounts IP30 rated metal enclosure with included DIN-rail and wall mount hardware Switching Capacity 12 Gbps switching capacity Redundant Power Dual redundant power inputs with overload current protection (power supply sold separately models: (model: TI-S12048) Alarm Relay Alarm relay triggered by power failure of primary and/or redundant power Jumbo Frame Sends larger packets, or Jumbo Frames (up to 9 KB), for increased performance Extreme Temperatures Industrial switch is rated for an operating temperature range of -40 - 75 °C (-40 - 167 °F) Shock and Vibration Resistant Rated for shock (EN 60068-2-27), freefall (EN 60068-2-32), and vibration (EN 60068-2-6) Grounding Point Grounding point protects equipment from external electrical surges

Product Type	Ethernet Switch
Brand Name	TRENDnet
Manufacturer	TRENDnet
Product Model	TI-PG62B
Product Name	6-Port Industrial Gigabit PoE+ DIN-Rail Switch 12 - 56 V
Manufacturer Part Number	TI-PG62B
Manufacturer Website Address	http://www.trendnet.com
Manageable	No
Environmentally Friendly	Yes
Environmental Certification	WEEERoHS
Package Contents	6-Port Industrial Gigabit PoE+ DIN-Rail Switch 12 - 56 V Quick Installation Guide Removable terminal block DIN-rail and wall mount kit
Ethernet Technology	Gigabit Ethernet
Media Type Supported	Twisted PairOptical Fiber
Network Technology	1000Base-T1000Base-X
Number of Total Expansion Slots	2
Number of SFP Slots	2
Shared SFP Slot	No
Expansion Slot Type	SFP
Modular	Yes
Uplink Port	No
Stack Port	No
Total Number of Network Ports	4
Port/Expansion Slot Details	4 x Gigabit Ethernet Network2 x Gigabit Ethernet Expansion Slot
Height	1.8"
Width	5.6"
Depth	4.1"
Form Factor	Rail-mountableWall Mountable
Weight (Approximate)	1.54 lb
Limited Warranty	Lifetime
Layer Supported	2
