Tripp Lite MTP/MPO to 8xLC Singlemode Breakout Patch Cable, Yellow, 3 m N390-03M-8LC-AP

Tripp Lite MTP/MPO to 8xLC Singlemode Breakout Patch Cable, Yellow, 3 m N390-03M-8LC-AP
Price $220.99
Manufacturer: Tripp Lite
Mfg Number: N390-03M-8LC-AP
Condition: New
UPC: 037332205599
The N390-03M-8LC-AP MTP/MPO to 8xLC Singlemode Breakout Patch Cable supports 40/100 Gb Ethernet speeds and is designed for high-density fiber patching between data center MDFs (main distribution frames) and IDFs (intermediate distribution frames) in enterprise installations. It's optimized for QSFP+ 40GBASE-PLR4 and QSFP28 100GBASE-PSM4 networks. Its plenum-rated jacket makes it ideal for connecting switches, hubs, routers and other high-speed network components in ceilings, walls and ducts.The 12-fiber MTP/MPO connector is about the same size as an SC connector, but is 12 times denser, freeing up rack space for other cables. The APC connector is angled to prevent infrared light entering the fiber from bouncing back into the laser. The N390-03M-8LC-AP is tested for low insertion loss and back reflection on every connector and attenuation loss that meets or exceeds current standards. The N390-03M-8LC-AP uses eight fibers to fully transmit 40GBASE-PLR4 with four fibers transmitting at 10 Gbps in each direction. Its slim, space-saving uniboot design allows easier cable management. The LC UPC connector's premium-grade ceramic ferrule is designed for fast applications of 10 GbE and higher.The singlemode cable is colored yellow for instant identification in a crowded switch or patch panel. Push/pull tab connectors are easily accessible in high-density data center environments and make the plug-and-play cable easy to install and remove with one hand.
Product TypeNetwork Cable
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelN390-03M-8LC-AP
Product NameN390-03M-8LC-AP MTP/MPO to 8xLC Singlemode Breakout Patch Cable, Yellow, 3 m
Manufacturer Part NumberN390-03M-8LC-AP
Manufacturer Website Addresshttp://www.tripplite.com
Environmentally FriendlyYes
Environmental CertificationRoHS
Cable CharacteristicPatch Cable
Connector on First End1 x MTP/MPO Female Network
Connector on Second End8 x LC Male Network
Cable TypeFiber Optic
Core/Cladding Diameter8.3/125 µm
Fiber Optic ModeSingle-mode
FeaturesAngled ConnectorSlimlineUniboot Connector
Data Transfer Rate12.50 GB/s
Device SupportedNetwork DeviceSwitchHubRouter
Cable Length9.84 ft
Limited WarrantyLifetime
