Tripp Lite 13-Outlets PDU PDU1226

Tripp Lite 13-Outlets PDU PDU1226
Price $142.17
Manufacturer: Tripp Lite
Mfg Number: PDU1226
SKU:
Condition: New
UPC: 037332255754
Accessories
Description
Single-Phase 120V PDU Distributes Network-Grade Power to Multiple LoadsThis basic PDU is an ideal no-frills unit for networking, telecom, security, audio/video and sound reinforcement applications. Recommended for high-density IT environments, the PDU1226 features a single breakered load bank with 13 NEMA 5-15/20R outlets - 12 in the rear and one in front. A six-foot cord with NEMA 5-20P input plug connects to your facility's AC power source, generator or protected UPS system to distribute power to connected loads. Up-to-Date Safety Features Protect Your Vital EquipmentThe switchless design helps prevent an accidental shutdown, which could lead to costly downtime. A 20A circuit breaker protects connected components from dangerous overloads. Versatile Installation Options Give You Plenty of ChoicesThe reversible all-metal housing comes with mounting brackets for installation in 1U or 0U of space in an EIA-standard 19-inch rack. You can also reorient the brackets for permanent mounting under a counter or on a wall with user-supplied hardware.
Specifications
Product Type PDU
Manufacturer Part Number PDU1226
Manufacturer Website Address http://www.tripplite.com
Manufacturer Tripp Lite by Eaton
Product Model PDU1226
Product Name PDU1226 13-Outlets PDU
Brand Name Tripp Lite
Package Contents
  • PDU1226 13-Outlets PDU
  • Rack-mounting Hardware
  • Owner's Manual
Country of Origin China
Environmentally Friendly Yes
Environmental Certification RoHS
Weight (Approximate) 5.20 lb
Mount Type Rack-mountable Wall-mountable
Rack Height 1U
Height 1.8"
Width 17.5"
Depth 4.5"
Mounting Orientation Horizontal/Vertical
Input Voltage 120 V AC
Output Voltage 100 V AC 120 V AC 127 V AC
Input Current 20 A
Power Rating (Watt) 2500 W
Protection Type Overload Protection Circuit Protection Accidental Power Shutdown
Plug/Connector Type NEMA 5-20P
Phase Single Phase
Receptacle Type NEMA 5-15/20R
PDU Type Basic
Receptacle Detail 13 x NEMA 5-15/20R
Limited Warranty 5 Year
