Tripp Lite 14-Outlets PDU PDUH20-ISO6

Single-Phase 120V PDU Distributes Network-Grade Power to Multiple LoadsThis basic PDU is an ideal no-frills unit for telecom, security, audio/video and a wide variety of general portable and stationary rack-mount applications. Recommended for network-grade IT environments, the PDUH20-ISO6 features 12 NEMA 5-20R outlets in the rear and two 5-15R outlets in front. A six-foot cord with L5-20P input plug (and included 5-20P adapter) connects to your facility's AC power source, generator or protected UPS system to distribute power to connected loads. 3840 Joules Fight Back Against Unexpected Power SurgesProtecting your valuable electronics is ISOBAR® network-grade AC surge and noise suppression. A 3840-joule surge protection rating defends your sensitive electronic components against even the strongest power surges, spikes and line noise. The PDUH20-ISO6 covers full normal (H-N) and common (N-G/H-G) protection modes. A green LED confirms your connected equipment is protected. Up-to-Date Safety Features Protect Your Vital EquipmentThe switchless design helps prevent an accidental shutdown, which could lead to costly downtime. A 20A circuit breaker protects connected components from dangerous overloads. A red LED signals a suppressor or wiring fault. Versatile Installation Options Give You Plenty of ChoicesThe reversible all-metal housing comes with mounting brackets for installation in 1U of space or 0U vertical mounting in an EIA-standard 19-inch rack. You can also reorient the brackets for permanent mounting under a counter or on a wall with user-supplied hardware.

Product Type	PDU
Manufacturer Part Number	PDUH20-ISO6
Manufacturer Website Address	http://www.tripplite.com
Manufacturer	Tripp Lite by Eaton
Product Model	PDUH20-ISO6
Product Name	PDUH20-ISO6 14-Outlets PDU
Brand Name	Tripp Lite
Package Contents	PDUH20-ISO6 14-Outlets PDU NEMA 5-20P Input Adapter Rack-Mounting Hardware Owner's Manual
Country of Origin	China
Environmentally Friendly	Yes
Environmental Certification	RoHS
Weight (Approximate)	4.60 lb
Mount Type	Rack-mountable Wall-mountable
Rack Height	1U
Height	1.8"
Width	17.5"
Depth	4.5"
Mounting Orientation	Horizontal/Vertical
Input Voltage	120 V AC
Output Voltage	100 V AC 120 V AC 127 V AC
Input Current	20 A
Power Rating (Watt)	2030 W
Protection Type	Surge Protection Spike Protection Accidental Power Shutdown Overload Protection Circuit Protection
Plug/Connector Type	NEMA L5-20P NEMA 5-20P
Phase	Single Phase
Receptacle Type	NEMA 5-15R NEMA 5-15/20R
PDU Type	Basic
Receptacle Detail	2 x NEMA 5-15R 12 x NEMA 5-15/20R
Limited Warranty	2 Year
