Tripp Lite Switched Metered 16-Outlets PDU PDUMH20NET

PDUMH20NET Switched, Metered, 1U horizontal rack PDU supports 20A maximum capacity at 120V (agency de-rated to 16 amps). Includes attached L5-20P input cordset with 5-20P adapter and 16 5-15/20R switched outlets (8 front / 8 rear). Visual and remote current monitoring tracks the output current. Supports 1U horizontal rackmount installation in 2 or 4 post racks, plus 0U vertical, wallmount and under-counter installation in many applications. Included cord retention brackets keeps vital network equipment plugged in and continuously powered.

Product Type	PDU
Product Series	Switched Metered
Brand Name	Tripp Lite
Manufacturer	Tripp Lite
Product Model	PDUMH20NET
Product Name	Switched Metered PDUMH20NET 16-Outlets PDU
Manufacturer Part Number	PDUMH20NET
Manufacturer Website Address	http://www.tripplite.com
Package Contents	Switched Metered PDUMH20NET 16-Outlets PDU L5-20P Input Power Cord 5-20P Plug Adapter Installable 1U Mounting Brackets PowerAlert Software User Manual
Height	1.8"
Width	17.5"
Depth	15.5"
Rack Height	1U
Form Factor	Rack-mountableVerticalWall Mountable
Weight (Approximate)	12.50 lb
Input Voltage	120 V AC
Output Voltage	120 V AC
Input Receptacles	NEMA L5-20P
Output Receptacles	16 x NEMA 5-15/20R
