Tripp Lite Metered 12-Outlets PDU PDUMH30

Tripp Lite's PDUMH30 AC power distribution unit offers a digital current monitor and provides 30 amps of 120 volt capacity in a versatile multi-mount cabinet (agency de-rated to 24A continuous). Detachable mounting flanges are configurable for wallmount, under-counter, or 1U/0U rackmount installation. Uses only 1U of rack space when installed in any 19-inch rack, with the potential for zero U mounting in the cable management area of most rack enclosures. Built-in digital ammeter display offers continuous visual input current monitoring data for the entire PDU. Attractive rackmount housing with 12 rear-facing outlets measures only 4.5 inches in depth. Output is arranged in two separately breakered 20A output loading banks. Unfiltered electrical pass-through without a power switch makes the PDUMH30 ideal for distributing UPS or generator power in rack enclosures, network closets, and more. Includes 12 rear-facing NEMA 5-15/20R outlets, 15-ft. AC power cord with L5-30P input plug. TVSS grounding lug and rugged all-metal rackmount case design.

Product Type	PDU
Product Series	Metered
Brand Name	Tripp Lite
Manufacturer	Tripp Lite
Product Model	PDUMH30
Product Name	Metered PDUMH30 12-Outlets PDU
Manufacturer Part Number	PDUMH30
Manufacturer Website Address	http://www.tripplite.com
Package Contents	Metered PDUMH30 12-Outlets PDU Owner's Manual with Warranty Information
Height	1.8"
Width	17.5"
Depth	6.5"
Rack Height	1U
Form Factor	Horizontal RackmountVertical Rackmount
Weight (Approximate)	7 lb
Input Voltage	120 V AC
Output Voltage	120 V AC
Input Receptacles	NEMA L5-30P
Output Receptacles	12 x NEMA 5-15/20R
Protection Type	Overload Protection
Limited Warranty	Lifetime
