Tripp Lite SmartPro 3000VA Rack-mountable UPS SMART3000CRMXLN

Tripp Lite SmartPro 3000VA Rack-mountable UPS SMART3000CRMXLN
Price $2,361.50
Manufacturer: Tripp Lite
Mfg Number: SMART3000CRMXLN
Condition: New
UPC: 037332248541
3kVA/2.88kW/120V Battery Backup for PC Networks, Security Systems or Digital Signage The SmartPro® line-interactive SMART3000CRMXLN UPS system with AVR provides reliable battery backup and AC power protection against blackouts, brownouts, overvoltages, surges and line noise that can damage valuable electronics or destroy data. The nine-outlet 120V battery backup with 0.96 power factor is ideal protection for small networks, wiring closets, security systems, telecom, high-end PC gaming, digital signage equipment and other professional applications, including retail, casino and hotel/motel management. Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages Backup support allows you to work through short power failures and gives you enough time to safely save files and shut down your system in case of a prolonged blackout. Backup time varies according to load, but the field-replaceable, hot-swappable internal battery should keep a half load (1440W) powered as long as 19 minutes and a full load (2880W) up to 7.5 minutes. For mission-critical applications demanding scalable extended runtime, the UPS supports external battery packs, such as Tripp Lite's BP48V27-2US (sold separately). Pre-Installed WEBCARDLX Network Interface Offers 24/7 Remote Access for Monitoring and Control The Java-free HTML5-based WEBCARDLX enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Automated alerts help prevent accidental overloads, power loss and downtime. WEBCARDLX allows you to use the Auto Probe feature, which can prevent costly service calls by automatically rebooting non-responsive network devices. 9 NEMA Outlets Protect Your Connected Components One L5-30R and eight 5-15/20R outlets provide battery backup, 570 joules of surge protection and voltage regulation for your crucial components. Three independently switched single-outlet 5-15/20R load banks enable both scheduled and real-time remote rebooting and load shedding. Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts and overvoltages. The SMART3000CRMXLN can correct brownouts as low as 83V and overvoltages as high as 145V back to nominal 120V power continuously, all while keeping the battery fully charged and ready to take over in case of power failure. Premium Protection from EMI/RFI Line Noise Helps Your Equipment Perform Better This UPS system filters out disruptive electromagnetic and radio frequency interference that can inflict hardware damage or data loss. This EMI/RFI filtering also helps your connected components perform better and last longer. Designed for High Efficiency to Help You Save Money and Protect the Environment A 97% efficiency rating reduces BTU emissions, energy consumption and, ultimately, your energy costs. Audible Alarm and Diagnostic LEDs Keep You Informed Around the Clock Five front-panel LEDs monitor line power, battery power, overload, voltage regulation and battery low/replace status. The alarm sounds to warn you in case of power failure, overload and low battery.
Battery Chemistry Lead Acid
Hot Swappable Yes
Backup/Run Time (Half Load) 19 Minute
Backup/Run Time (Full Load) 7.50 Minute
Battery Characteristics Valve-regulated
Replaceable Battery Yes
DC System Voltage 48 V DC
Typical Battery Recharge Time 7.20 Hour
Status Indicators

LED Indicators:

  • 5 LEDs Indicate Line Power
  • Battery Power
  • Overload
  • Voltage Regulation
  • Battery Low/Replace Status
Network (RJ-45) Yes
Serial Port Yes
EPO Port Yes
USB (HID Compliant) Port Yes
Thermal Dissipation 157.97 W
Maximum Operating Temperature 104°F (40°C)
Storage Temperature 5°F (-15°C) - 122°F (50°C)
Sound Emission (A-Weighted) 45 dB(A)
Product Type Line-interactive UPS
Manufacturer Part Number SMART3000CRMXLN
Manufacturer Website Address http://www.tripplite.com
Manufacturer Tripp Lite by Eaton
Product Model SMART3000CRMXLN
Product Name SmartPro SMART3000CRMXLN 3000VA Rack-mountable UPS
Product Line SmartPro
Brand Name Tripp Lite
Network Management SNMP/Telnet/SSH
Alarm Power Failure Overload Low Battery
Package Contents
  • SmartPro SMART3000CRMXLN 3000VA Rack-mountable UPS
  • Pre-Installed WEBCARDLX Network Management Card
  • USB Cable
  • DB9 Cable
  • EPO Cable
  • Rack-mounting Hardware
  • Owner's Manual
Country of Origin China
Environmentally Friendly Yes
Environmental Certification RoHS
Weight (Approximate) 102.01 lb
Form Factor Rack-mountable
Rack Height 4U
Height 6.9"
Width 17.3"
Depth 17.8"
Input Voltage 120 V AC
Output Voltage 110 V AC 115 V AC 120 V AC
Load Capacity 3000 VA/2880 W
Surge Energy Rating 570 J
Waveform Type Sine Wave
Application/Usage Digital Signage Security System Casino Gaming Console Network Device Desktop Computer Mission Critical Equipment Retail Building Wiring Closet Hotel/Motel Management
Dataline Protection RJ-11
Overload Protection Yes
Plug/Connector Type NEMA L5-30P
Phase Single Phase
Receptacle Type NEMA 5-15/20R NEMA L5-30R
EMI/RFI Noise Filter Yes
Transfer Time 5 ms
Receptacle Detail 8 x NEMA 5-15/20R 1 x NEMA L5-30R
Limited Warranty 3 Year
