Tripp Lite SmartPro 500VA Rack/Tower UPS SMART500RT1UN

Tripp Lite SmartPro 500VA Rack/Tower UPS SMART500RT1UN
Price $622.93
Manufacturer: Tripp Lite
Mfg Number: SMART500RT1UN
Condition: New
UPC: 037332224170
500VA/300W/120V Battery Backup for PC Networks, Security Systems or Digital Signage The SmartPro® line-interactive SMART500RT1UN UPS system with AVR provides reliable battery backup and AC power protection against blackouts, brownouts, overvoltages, surges and line noise that can damage valuable electronics or destroy data. The seven-outlet 120V battery backup is ideal protection for rack-mount equipment in your server room or network closet. Allows Time to Back Up Critical Files During a Blackout Backup support allows you to work through short power failures and gives you enough time to safely save files and shut down your system in case of a prolonged blackout. Backup time varies according to load, but the line-interactive UPS system should keep a half load (150W) powered as long as 14 minutes and a full load (300W) up to three minutes. Included WEBCARDLX Network Interface Offers 24/7 Access The Java-free HTML5-based WEBCARDLX interface enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimal communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities, including temperature and humidity conditions. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP. 6 NEMA Outlets Protect Your Connected Components Six 5-15R outlets provide battery backup, 567 joules of surge protection and voltage regulation for your crucial components. Five are UPS-supported, and one is surge-only to connect peripherals not requiring battery backup. One UPS-supported outlet is switchable, allowing you to power its connected device on and off remotely to reset or reboot it or to shed a less significant load to extend battery runtime for more critical equipment. Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts and overvoltages. The SMART500RT1UN maintains regulated 120V nominal output during brownouts as low as 90V, while keeping the battery fully charged and ready to take over in case of power failure. The internal batteries are field-replaceable and hot-swappable. Premium Protection from EMI/RFI Line Noise Helps Your Equipment Perform Better This UPS system filters out disruptive electromagnetic and radio frequency interference that can inflict hardware damage or data loss. This EMI/RFI filtering also helps your connected components perform better and last longer. Designed for High Efficiency to Help You Save Money and Protect the Environment A 96% efficiency rating reduces BTU emissions, energy consumption and, ultimately, your energy costs. LED Indicators and Audible Alarms Keep You Informed Five front-panel LEDs keep you apprised of line power, battery power, overload, voltage regulation and battery low/replace status at a glance. A multi-function alarm sounds to warn you of power failure, overload and low-battery conditions.
Hot Swappable Yes
Backup/Run Time (Half Load) 14 Minute
Backup/Run Time (Full Load) 3 Minute
Replaceable Battery Yes
DC System Voltage 12 V DC
Typical Battery Recharge Time 14.40 Hour
Status Indicators

LED Indicators:

  • 5 LEDs Indicate Line Power
  • Battery Power
  • Overload
  • Voltage Regulation
  • Battery Low/Replace Status
Serial Port Yes
EPO Port Yes
USB (HID Compliant) Port Yes
Thermal Dissipation 12.90 W
Maximum Operating Temperature 104°F (40°C)
Storage Temperature 5°F (-15°C) - 122°F (50°C)
Product Type Line-interactive UPS
Manufacturer Part Number SMART500RT1UN
Manufacturer Website Address http://www.tripplite.com
Manufacturer Tripp Lite by Eaton
Product Model SMART500RT1UN
Product Name SmartPro SMART500RT1UN 500VA Rack/Tower UPS
Product Line SmartPro
Brand Name Tripp Lite
Network Management SNMP/Telnet/SSH
Alarm Power Failure Overload Low Battery
Package Contents
  • SmartPro SMART500RT1UN 500VA Rack/Tower UPS
  • WEBCARDLX Network Management Card
  • Micro USB to USB-A
  • USB Cable
  • DB9 Cable
  • EPO Cable
  • Rack-Mounting Hardware
  • Owner's Manual
Country of Origin China
Environmentally Friendly Yes
Environmental Certification RoHS
Weight (Approximate) 17.60 lb
Form Factor Rack/Tower
Rack Height 1U
Height 1.7"
Width 17.3"
Depth 11.3"
Input Voltage 120 V AC
Output Voltage 120 V AC 110 V AC 115 V AC
Load Capacity 500 VA/300 W
Surge Energy Rating 567 J
Waveform Type Sine Wave
Application/Usage Telecommunication Security System Digital Signage Network Closet Server Room Electronic Mission Critical Equipment Business POS Terminal VoIP Desktop Computer
Overload Protection Yes
Plug/Connector Type NEMA 5-15P
Phase Single Phase
Receptacle Type NEMA 5-15R
EMI/RFI Noise Filter Yes
Number of Surge-only Outlets 1
Transfer Time 4 ms
Receptacle Detail 6 x NEMA 5-15R
Limited Warranty 2 Year
