Tripp Lite SmartPro 750VA Rack/Tower UPS SMART750RMXL2UN

Tripp Lite SmartPro 750VA Rack/Tower UPS SMART750RMXL2UN
Price $1,030.52
Manufacturer: Tripp Lite
Mfg Number: SMART750RMXL2UN
SKU:
Condition: New
UPC: 037332256409
Accessories
Description
750VA/600W/120V Battery Backup for PC Networks, Security Systems or Digital Signage The SmartPro® line-interactive SMART750RMXL2UN UPS system with AVR provides reliable battery backup and AC power protection against blackouts, brownouts, overvoltages, surges and line noise that can damage valuable electronics or destroy data. The six-outlet 120V battery backup is ideal protection for small networks, wiring closets, security systems, telecom, high-end PC gaming, digital signage equipment and other professional applications, including retail, casino and hotel/motel management. Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages The user-replaceable, hot-swappable internal battery provides 20.7 minutes of support at half load (300W) and 8.5 minutes at full load (600W), allowing you to work through short power failures and giving you enough time to safely save files and shut down your system in case of a prolonged blackout. For mission-critical applications demanding scalable extended runtime, the UPS supports external battery packs, such as Tripp Lite's BP24V36-2US (sold separately). The intelligent battery management system extends battery life. WEBCARDLX Network Interface Offers 24/7 Remote Access for Monitoring and Control The Java-free HTML5-based WEBCARDLX enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Automated alerts help prevent accidental overloads, power loss and downtime. WEBCARDLX allows you to use the Auto Probe feature, which can prevent costly service calls by automatically rebooting non-responsive network devices. 6 NEMA Outlets Protect Your Connected Components Six 5-15R outlets provide battery backup, 570 joules of surge protection and voltage regulation for your crucial components. Two independently switched two-outlet load banks enable both scheduled and real-time remote rebooting and load shedding. Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts and overvoltages. The SMART750RMXL2UN can correct brownouts as low as 83V and overvoltages as high as 147V back to nominal 120V power continuously, all while keeping the battery fully charged and ready to take over in case of power failure. Premium Protection from EMI/RFI Line Noise Helps Your Equipment Perform Better This UPS system filters out disruptive electromagnetic and radio frequency interference that can inflict hardware damage or data loss. This EMI/RFI filtering also helps your connected components perform better and last longer. Designed for High Efficiency to Help You Save Money and Protect the Environment A 95% efficiency rating reduces BTU emissions, energy consumption and, ultimately, your energy costs. Silenceable Alarm and Easy-to-Read LCD Keep You Informed Around the Clock The front-panel LCD lets you monitor important data, such as load level, power factor, voltage, battery charge and estimated runtimes. It rotates for comfortable viewing in both rack and tower configurations. The audible alarm sounds for power failure, low battery and overloads. You may silence it using the built-in switch or disable it.
Specifications
Hot Swappable Yes
Backup/Run Time (Half Load) 20.70 Minute
Backup/Run Time (Full Load) 8.50 Minute
Replaceable Battery Yes
DC System Voltage 24 V DC
Typical Battery Recharge Time 4.50 Hour
Status Indicators

Front Panel LCD Information And Configuration Screen:

  • UPS and Site Power Status
  • Operating Data
  • Plus Configuration Of Voltage
  • Frequency
  • Operating Mode
  • Alarm Function and A Variety Of Additional Options
Serial Port Yes
EPO Port Yes
USB (HID Compliant) Port Yes
Thermal Dissipation 31.94 W
Maximum Operating Temperature 104°F (40°C)
Storage Temperature 5°F (-15°C) - 122°F (50°C)
Sound Emission (A-Weighted) 45 dB(A)
Product Type Line-interactive UPS
Manufacturer Part Number SMART750RMXL2UN
Manufacturer Website Address http://www.tripplite.com
Manufacturer Tripp Lite by Eaton
Product Model SMART750RMXL2UN
Product Name SmartPro SMART750RMXL2UN 750VA Rack/Tower UPS
Product Line SmartPro
Brand Name Tripp Lite
Network Management SNMP/Telnet/SSH
Alarm UPS StartUp Power Failure Low Battery Overload UPS Fault Remote Shutdown
Package Contents
  • SmartPro SMART750RMXL2UN 750VA Rack/Tower UPS
  • WEBCARDLX Network Management Card
  • USB Cable
  • DB9 Cable
  • EPO Cable
  • Rack-mounting Hardware
  • Owner's Manual
Country of Origin China
Environmentally Friendly Yes
Environmental Certification RoHS
Weight (Approximate) 35.40 lb
Form Factor Rack/Tower
Rack Height 2U
Height 3.5"
Width 17.4"
Depth 13.1"
Input Voltage 120 V AC
Output Voltage 110 V AC 115 V AC 120 V AC
Load Capacity 750 VA/600 W
Surge Energy Rating 570 J
Waveform Type Pure Sine Wave
Output Frequency 60 Hz
Input Frequency 60 Hz
Application/Usage Telecommunication Network Device Network Closet Gaming Console Digital Signage Retail Building Casino Mission Critical Equipment Server Security System Hotel/Motel Management Wiring Closet
Overload Protection Yes
Plug/Connector Type NEMA 5-15P
Phase Single Phase
Receptacle Type NEMA 5-15R
EMI/RFI Noise Filter Yes
AVR Yes
Transfer Time 4 ms
Receptacle Detail 6 x NEMA 5-15R
Limited Warranty 2 Year
