Tripp Lite SmartOnline E 5kVA Tower/Rack-Mountable UPS SU5000RT4UTF

Tripp Lite SU5000RT4UTF 5000VA / 5kVA / 4500 watt on-line, double-conversion UPS system offers complete power protection for critical server, network and telecommunications equipment in a 6U rack/tower configuration. Maintains full-time sine wave output within 2% of 208 and 120V nominal at 60Hz during brownouts as low 100V and overvoltages as high as 300V. Double-conversion operation converts raw input from AC to DC, then resynthesizes output power back to perfect sine wave AC with enhanced protection from harmonic distortion, fast electrical impulses and other hard-to-solve power problems not addressed by other UPS types. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Front panel LEDs and LCD readout with scroll controls support front-panel visual monitoring of all major UPS functions. L6-30P input, plus 2 L6-30R, 2 L6-20R and 12 5-15/20R outlets.

Product Type	Dual Conversion Online UPS
Product Series	E
Brand Name	Tripp Lite
Manufacturer	Tripp Lite
Product Model	SU5000RT4UTF
Product Name	SmartOnline E SU5000RT4UTF 5kVA Tower/Rack-Mountable UPS
Product Line	SmartOnline
Manufacturer Part Number	SU5000RT4UTF
Manufacturer Website Address	http://www.tripplite.com
Batteries	User Replaceable Hot-swappable
Backup/Run Time	0.06 Hour 4.50 kW Full Load0.18 Hour 2.25 kW Half Load
Battery Recharge Time	6 Hour
Height	6.9"
Width	17.5"
Depth	21"
Form Factor	6U Tower/Rack Mountable
Weight (Approximate)	113.60 lb
Receptacles	2 x NEMA L6-20R2 x NEMA L6-30R12 x NEMA 5-15/20R
Plug/Connector Type	NEMA L6-30P
Interfaces/Ports	DB-9 RS-232 SerialUSB
Input Voltage Range	208 V AC Nominal
Load Capacity	5 kVA/4.50 kW
Input Voltage	220 V AC
Output Voltage	120 V AC Nominal208 V AC Nominal
Network Management	SNMP Manageable Included
Package Contents	SmartOnline E SU5000RT4UTF 5kVA Tower/Rack-Mountable UPS PowerAlert Software CD-ROM USB Cable Serial Cable EPO Cable 2 x Sets of Adjustable 4 Post Rack Rails
Limited Warranty	2 Year
