Tripp Lite SmartOnline 750VA Tower/Rack Mountable SU750RTXL2UN

Tripp Lite SmartOnline 750VA Tower/Rack Mountable SU750RTXL2UN
Price $970.21
Manufacturer: Tripp Lite
Mfg Number: SU750RTXL2UN
SKU:
Condition: New
UPC: 037332190758
Accessories
Description
750VA online, double-conversion UPS system for critical server, network and telecommunications equipment. 2U rackmount form factor with an installed depth of only 13.5 inches. Extended runtime available with optional BP24V15RT2U (limit 1), BP24V28-2U (limit 1), BP24V70-3U (multi-pack compatible) and BP24V36-2US (multi-pack compatible) external battery packs. Full-time sine wave 100, 110 or 120V output with +/-2% voltage regulation. Online, double-conversion Uninterruptible Power Supply (UPS) actively converts raw incoming AC power to DC, then re-converts output back to completely regulated, filtered AC output. Operates continuously without using battery power during brownouts to 65V and overvoltages to 150. NEMA 5-15P input plug; NEMA 5-15R output receptacles. Network-grade AC surge and noise suppression. Zero transfer time between AC and battery operation. Network management interfaces support simultaneous communications via USB port, DB9 serial port and SNMPWEBCARD. Built-in DB9 port offers both enhanced RS-232 enabled monitoring data, plus contact closure monitoring ability. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all 3 network interfaces. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. Integrated two-bank PDU switching supports load shedding and remote reboot of connected equipment. 3-stage metered current monitoring and battery charge status LEDs. LED display panel easily rotates for viewing in rackmount or tower configurations. Dataline surge suppression for dialup, DSL or network Ethernet connection. Utility power and voltage regulation LEDs. Audible alarm. Self-test. Fault-tolerant auto-bypass mode. 4-post rackmount accessories included; 2-9USTAND tower kit and 2POSTRMKITWM 2-post rack & wallmount accessories available. Field-replaceable, hot-swappable internal batteries and external battery packs. $250,000 Ultimate Lifetime Insurance (U.S., Canada, and Puerto Rico only).
Specifications
Product TypeDual Conversion Online UPS
Brand NameTripp Lite
ManufacturerTripp Lite
Product ModelSU750RTXL2UN
Product NameSmartOnline SU750RTXL2UN 750VA Tower/Rack Mountable
Product LineSmartOnline
Manufacturer Part NumberSU750RTXL2UN
Manufacturer Website Addresshttp://www.tripplite.com
Green CompliantYes
Green Compliance Certificate/AuthorityRoHS
Package Contents
  • SmartOnline SU750RTXL2UN 750VA Tower/Rack Mountable
  • PowerAlert Software and Cabling
  • Mounting Hardware for 4-post Rack Enclosures
  • Instruction Manual
Backup/Run Time (Full Load)4 Minute
Load Capacity (VA)750 VA
Load Capacity (Watt)600 W
Input Voltage100 V AC110 V AC120 V AC
Output Voltage100 V AC110 V AC120 V AC
Height3.5"
Width17.5"
Depth13.5"
Rack Height2U
Form FactorTower/Rack Mountable
Weight (Approximate)29 lb
Receptacles6 x NEMA 5-15R
Limited Warranty2 Year
