Tripp Lite UPS Maintenance Bypass Panel for SUT30K - 3 Breakers SUT30KMBP

Bypass an SUT30K UPS to Perform MaintenanceFor use with Tripp Lite's SUT30K 3-phase UPS system, the SUT30KMBP maintenance bypass panel (MBP) maintains total continuity of power to connected load circuits when bypass of the UPS is required for regular service and maintenance. This UPS maintenance bypass panel has three 4-pole circuit breakers for Input, Bypass and Output. The breakers have removable handles to allow the panel's trim cover to be removed for internal access. The short circuit rating is 10 kAIC. Maximum current capacity is 125A. Convenient Wall-Mount InstallationMade of galvanized steel, the service bypass panel has rear mounting holes for installation on a smooth and solid wall (mounting hardware not included). One-Year WarrantyThe SUT30KMBP is backed by a one-year limited warranty, ensuring reliability and performance.

Product Type	Bypass Panel
Manufacturer Part Number	SUT30KMBP
Manufacturer Website Address	http://www.tripplite.com
Manufacturer	Tripp Lite by Eaton
Product Model	SUT30KMBP
Product Name	UPS Maintenance Bypass Panel for SUT30K - 3 Breakers
Brand Name	Tripp Lite
Package Contents	UPS Maintenance Bypass Panel for SUT30K - 3 Breakers Installation and Operation Manual
Compatibility	Tripp Lite SUT30K UPS
Country of Origin	China
Environmentally Friendly	Yes
Environmental Certification	RoHS
Weight (Approximate)	28 lb
Form Factor	Wall-mountable
Height	17.5"
Width	20"
Depth	4.6"
Input Voltage	120 V AC 230 V AC
Current	125 A
Limited Warranty	1 Year
