Tripp Lite UPS Maintenance Bypass Panel for SUT60K - 3 Breakers SUT60KMBP

Bypass an SUT60K UPS to Perform Maintenance For use with Tripp Lite's SUT60K 3-phase UPS system, the SUT60KMBP maintenance bypass panel (MBP) maintains total continuity of power to connected load circuits when bypass of the UPS is required for regular service and maintenance. This UPS maintenance bypass panel has three 4-pole circuit breakers for Input, Bypass and Output. The breakers have removable handles to allow the panel's trim cover to be removed for internal access. Maximum current capacity is 225A. Convenient Wall-Mount Installation Made of galvanized steel, the service bypass panel has rear mounting holes for installation on a smooth and solid wall (mounting hardware not included). One-Year Warranty The SUT60KMBP is backed by a one-year limited warranty, ensuring reliability and performance.

Product Type	Bypass Panel
Manufacturer Part Number	SUT60KMBP
Manufacturer Website Address	http://www.tripplite.com
Manufacturer	Tripp Lite by Eaton
Product Model	SUT60KMBP
Product Name	UPS Maintenance Bypass Panel for SUT60K - 3 Breakers
Brand Name	Tripp Lite
Package Contents	UPS Maintenance Bypass Panel for SUT60K - 3 Breakers Installation and Operation Manual
Compatibility	Tripp Lite SUT60K 3-phase UPS System
Country of Origin	Germany
Environmentally Friendly	Yes
Environmental Certification	RoHS
TAA Compliant	Yes
Weight (Approximate)	85 lb
Form Factor	Wall-mountable
Height	31.5"
Width	38.5"
Depth	5.9"
Input Voltage	120 V AC 230 V AC
Current	225 A
Plug/Connector Type	Hard Wire 4-wire (3P + N + E)
Limited Warranty	1 Year
