Tripp Lite UPS System SMART2200RMXL2U

Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for critical server, network and telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS) with built-in Auto-Voltage Regulation (AVR) actively corrects brownouts and overvoltages back to usable levels while maintaining a full battery charge. Interactive LCD/LED interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Network management interfaces support communications via USB, RS-232 and optional SNMPWEBCARD. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Switched output load banks enable scheduled and real-time remote reboot and load shedding of select outlets. LED/LCD display panel easily rotates for viewing in rackmount or tower configurations. Field-replaceable, hot-swappable battery modules.

Product Type	Line-interactive UPS
Brand Name	Tripp Lite
Manufacturer	Tripp Lite
Product Name	SMART2200RMXL2U UPS System
Product Line	SmartPro
Manufacturer Part Number	SMART2200RMXL2U
Manufacturer Website Address	http://www.tripplite.com
Maximum Battery Recharge Time	4.50 Hour
Backup/Run Time (Half Load)	16 Minute
Backup/Run Time (Full Load)	6 Minute
USB	Yes
Serial Port	Yes
Load Capacity (VA)	2.20 kVA
Load Capacity (Watt)	1.60 kW
Input Voltage	110 V AC
Output Voltage	120 V AC110 V AC
Country of Origin	China
Package Contents	SMART2200RMXL2U UPS System Poweralert Software CD-ROM USB, Serial And EPO Cabling Owner's Manual
Height	3.5"
Width	17.5"
Depth	19"
Rack Height	2U
Weight (Approximate)	64 lb
Receptacles	4 x NEMA 5-15R4 x NEMA 5-20R
Plug/Connector Type	NEMA 5-20P
Protection Type	Over VoltageUnder Voltage
Network Management	SNMP Manageable
Limited Warranty	2 Year Limited
