Tyan Thunder HX FA77B7119 B7119F77V10E4HR-2T-N FA77-B7119

Tyan Thunder HX FA77B7119 B7119F77V10E4HR-2T-N FA77-B7119
Price $5,305.47
Manufacturer: Tyan
Mfg Number: B7119F77V10E4HR-2T-N
SKU:
Model: FA77-B7119
Condition: New
UPC: 635872045738
Accessories
Description
Intel C621 Chip - 3 TB DDR4 SDRAM DDR4-2666/PC4-21300 Maximum RAM Support - 24 Total Memory Slots - Serial ATA/600 RAID Supported Controller - ASPEED AST2500 32 MB Graphic(s) - 14 2.5" Bay(s) - 10 SATA Interface(s) - Processor Support (Xeon Platinum, Xeon Gold) - 10 Gigabit Ethernet, Gigabit Ethernet - 4 USB 3.0 Port(s) - 4 x 4800 W - 3 Year
Specifications
Number of SATA Interfaces 10
Total Number of USB Ports 4
Number of USB 3.0 Ports 4
Controller Type Serial ATA/600
RAID Supported Yes
Graphics Controller Manufacturer ASPEED
Graphics Controller Model AST2500
Graphics Memory Capacity 32 MB
Product Type Barebone System
Manufacturer Part Number B7119F77V10E4HR-2T-N
Manufacturer Website Address http://www.tyan.com
Packaged Quantity 1
Manufacturer Tyan Computer Corp
Product Model FA77-B7119
Product Name Thunder HX FA77B7119 (B7119F77V10E4HR-2T-N)
Product Line Thunder HX
Brand Name Tyan
Number of Internal 2.5" Bays 14
Number of Total Expansion Bays 14
Number of Total Expansion Slots 13
Number of PCI Express x16 Slots 13
Maximum Memory Supported 3 TB
Memory Technology DDR4 SDRAM
Memory Standard DDR4-2666/PC4-21300
Number of Total Memory Slots 24
Package Contents
  • Thunder HX FA77B7119 (B7119F77V10E4HR-2T-N)
  • 1 x Quick Installation Guide
  • 1 x TYAN Device Driver CD
Environmentally Friendly Yes
Environmental Certification RoHS-6
Ethernet Technology 10 Gigabit Ethernet Gigabit Ethernet
Weight (Approximate) 60.63 lb
Form Factor Rack-mountable
Rack Height 4U
Height 6.9"
Width 17.2"
Depth 30.3"
Input Voltage 120 V AC 230 V AC
Number of Power Supplies Installed 4
Maximum Power Supply Wattage 4800 W
Limited Warranty 3 Year
Processor Supported Xeon Platinum Xeon Gold
Processor Socket Socket P LGA-3647
64-bit Processing Yes
Number of Processors Supported 2
Chipset Manufacturer Intel
Chipset Model C621
Operating System Supported Windows Server 2012 R2 Datacenter x64 Windows Server 2016 Red Hat Enterprise Linux 6.9 x64 Red Hat Enterprise linux 7.3 x64 Red Hat Enterprise linux 7.4 x64 Ubuntu 16.04 LTS x64
